Chapter 2 Product Introduction 3
EC20 Series PLC User Manual
Component Name Quantity Serial No. Note
SM Special auxiliary relay 256 SM0~SM255
S State relay 992 S0~ S991
T Timer 256 T0~T255
100ms precision: T0~T209
10ms precision: T210~T251
1ms precision: T252~T255
C Counter 256 C0~C255
16 bit common increasing counter: C0~C199
32 bit common decreasing counter: C200~C235
32 bit high-speed counter: C236~C255
D Data register 8000 D0~D7999
V Local data register 64 V0~V63
Z
Indexed addressing
register
16 Z0~Z15
SD Special data register 256 SD0~SD255
2.5 High-speed Input/Output Function
High-speed port
name
High-speed port type Input/output mode Max. frequency of input/output signal
X0, X1 Input High-speed pulse count
Single input: 50KHz;
X0~X5 input at the same time: frequency sum is 80KHz
X2~X5 Input High-speed pulse count Single input: 10KHz
Y0, Y1 (only suitable
for transistor output)
Output High-speed pulse output Two ports output independently: 100KHz
2.6 Filter Function Of Input Port
Function Description
Digital filter function X0~X17 provide digital filter function, and filter time is within 0~60mS, set by user’s program
Hardware filter function Other X input ports
2.7 Interrupt Source
Provide eight external interrupt inputs, the interrupt edge can be set by users and is corresponding to X0~X7 ports;
six high-speed counter interrupts; three inner timing interrupt sources.
2.8 Subroutine Call
At most 64 subroutines and 6-level subroutine nesting can be used. Support local variables and variable-alias, and
every subroutine can provide 16 parameters to be called at most.
2.9 Reinforced Debugging Function
Provide register-forced function, convenient for debugging and analyzing the user program, improving debugging
efficient. Permit the most 128 bit-registers and 16 word-registers.
2.10 Support Online Modification
Users can modify the program online during operation, which is greatly convenient for modifying and upgrading the
user program in important production situation.
