56
–
EN
01A11
CRT : 19 inch in-line gun, 90˚
deflection tube
Television system : NTSC-M
Closed caption system :§15.119/FCC
Video Heads : Rotary four-head
Tape width : 1/2 inch
Tape speed
SP : 33.40mm/sec.
LP : 16.67mm/sec.
SLP : 11.12mm/sec.
Tuner channel
TV VHF Low : #2~#6
TV VHF High : #7~#13
TV UHF : #14~#69
CATV
VHF : 5A
MID band : A5~A1, A~I
SUPER band : J~W
HYPER band : W+1~W+84
Product type: DVD Player
Discs: DVD video, Audio CD
Output signal format: NTSC color
Frequency response
(out put jack)
DVD (linear sound): 20 Hz to 22 kHz
(sample rate: 48 kHz)
20 Hz to 44 kHz
(sample rate: 96 kHz)
CD: 20 Hz to 20 kHz
Signal-to-noise ratio
(S/N ratio)(out put jack)
CD: 100 dB (EIAJ)
Dynamic range
(out put jack)
DVD (linear sound): 85 dB
CD: 84 dB (EIAJ)
Total distortion factor
CD: 0.07% (EIAJ)
Wow and flutter: Below the measurement
limitation (+/-0.001%
WPEAK) (EIAJ)
•
Designs and specifications are subject to change without notice and without our legal obligation.
•
If there is a discrepancy between languages, the default language will be English.
TV/VCR
DVD
GENERAL SPECIFICATIONS ELECTRICAL SPECIFICATIONS
Sound output: 2 speakers, 1W, 8 ohm
OTHER SPECIFICATIONS
Terminals
Antenna input: VHF/UHF/CATV
75 ohm unbalanced (F-type)
Video input: RCA connector [ 1
Audio L/R input: RCA connector [ 2
Headphone: 1/8” stereo (3.5 mm)
Coaxial digital
audio output: One pin jack,
500m Vpp (75 ohm)
Analog audio L/R
output : RCA connector [ 2
Remote control: Digital encoded
infrared light system
Operating
temperature: 5ºC to 40ºC
(41ºF~104ºF)
Power requirements: AC 120V, 60Hz
Power consumption
(Maximum): 85W
Picture tube: 19"
Dimensions: H:19-21/32” (500mm)
W:23-13/16” (605mm)
D:18-11/16” (475mm)
Weight: 48.5 lbs (22kg)
Accessories: Remote Control Unit with
2"AA"batteries
Owner’s Manual
SPECIFICATIONS
