Emerson EWD2004OM Supplement Service Manual

1-15-1 H9600LE
LEAD IDENTIFICATIONS
123
3
45
123
6
45
60
21
40
41
20
1
80
61
E C B
E C B
E C B
A
K
C
E
1 4
8 5
16
9
8
1
E
C
28
15
14
1
B1 E B2
C1 C2
PQ070XZ5MZP
BA3948FP-E2
1: Vin
2: Vc
3: Vo
4: Vadj
5: GND
1: CTL
2: Vcc
3: N.C.
4: OUT
5: C
6: GND
LA71205M-MPB-E
LA72670BM-MPB-E
QSZAA0RMS017
Note:
A: Anode
K: Cathode
E: Emitter
C: Collector
B: Base
R: Reference
S: Source
G: Gate
D: Drain
2SA1175(J,H,F)
2SC2785(J,H,F,K)
BA1F4M-T
BN1F4M-T
KRA103M
KRC103M
KTA1266(GR)
KTA1267(GR,Y)
KTC3193(Y)
KTC3199(Y,GR,BL)
2SA1015-GR(TPE2)
2SC1815-BL(TPE2)
2SC1815-GR(TPE2)
2SC1815-Y(TPE2)
2SC2120-Y(TPE2)
KTC3198(Y,GR)
KTC3203(Y)
2SC536NF-NPA-AT
2SC536NG-NPA-AT
EL817A
EL817B
EL817C
LTV-817B-F
LTV-817C-F
PS2561A-1(Q,W)
MID-32A22F
PT204-6B-12
KIA4558P
NJM4558D
BU4053BCF
CD4053BCSJX
TC4053BF(N)
PT6313-S-TP
FMG4A T148
RN1511(TE85R)
