Emerson EWD2004OM Supplement Service Manual

20040227 1-18-1 H9600EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
Comparison Chart of Models and Marks
DVD MAIN CBA UNIT
MCV CBA
MAIN CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Model Mark
DVC860E A
DVC840E B
DVC845E C
EWD2204 D
Ref. No. Mark Description Part No.
A
B
C,D
DVD MAIN CBA UNIT
DVD MAIN CBA UNIT
DVD MAIN CBA UNIT
N79FPHUP
N79FQHUP
N79FNHUP
Ref. No. Mark Description Part No.
A
B
C,D
MCV CBA
MCV CBA
MCV CBA
Consists of the following
0VSA14910
0VSA15087
0VSA14939
MAIN CBA (MCV-A)
DVD OPEN/CLOSE CBA (MCV-C)
SENSOR CBA
----------
----------
0VSA14947
Ref. No. Mark Description Part No.
MAIN CBA (MCV-A) ----------
Consists of the following:
CAPACITORS
C013 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMASSL100
C017 CERAMIC CAP. YV Z 0.01µF/50V CCD1JZSYV103
C018 ELECTROLYTIC CAP. 470µF/16V M or CE1CMASDL471
ELECTROLYTIC CAP. 470µF/16V M CE1CMASTL471
C020 ELECTROLYTIC CAP. 1000µF/10V M or CE1AMZPDL102
ELECTROLYTIC CAP. 1000µF/10V M CE1AMZPTL102
C021 ELECTROLYTIC CAP. 470µF/6.3V M or CE0KMASDL471
ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASTL471
C023 ELECTROLYTIC CAP. 100µF/16V M or CE1CMASDL101
ELECTROLYTIC CAP. 100µF/16V M CE1CMASTL101
C030 CERAMIC CAP.(AX) B K 0.033µF/50V CA1J333TU011
C051 ELECTROLYTIC CAP. 10µF/16V M H7 CE1CMAVSL100
C053 ELECTROLYTIC CAP. 220µF/6.3V M or CE0KMASDL221
ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASTL221
C060 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EKB0B104
CHIP CERAMIC CAP. B K 0.1µF/16V or CHD1CKB0B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/25V
or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/16V CHD1CK30B104
C301 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMAVSL1R0
C302 CHIP CERAMIC CAP. CH J 390pF/50V or CHD1JJBCH391
CHIP CERAMIC CAP. CH J 390pF/50V or CHD1JJ3CH391
CHIP CERAMIC CAP. CG J 390pF/50V CHD1JJ3CG391
C303 PCB JUMPER D0.6-P5.0 JW5.0T
C304 CHIP CERAMIC CAP.(MELF) SL J 100pF/
50V or
CZM1JJBSL101
CHIP CERAMIC CAP.(MELF) SL J 100pF/
50V or
CZM1JJ3SL101
CHIP CERAMIC CAP. CH J 100pF/50V or CHD1JJBCH101
CHIP CERAMIC CAP.(1608) CH J 100pF/
50V or
CHD1JJ3CH101
CHIP CERAMIC CAP. CG J 100pF/50V CHD1JJ3CG101
C305 CHIP CERAMIC CAP.(MELF) SL J 100pF/
50V or
CZM1JJBSL101
CHIP CERAMIC CAP.(MELF) SL J 100pF/
50V or
CZM1JJ3SL101
CHIP CERAMIC CAP. CH J 100pF/50V or CHD1JJBCH101
CHIP CERAMIC CAP.(1608) CH J 100pF/
50V or
CHD1JJ3CH101
CHIP CERAMIC CAP. CG J 100pF/50V CHD1JJ3CG101
C307 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C308 ELECTROLYTIC CAP. 47µF/6.3V M H7 CE0KMAVSL470
C309 CHIP CERAMIC CAP. F Z 0.1µF/50V or CHD1JZB0F104
CHIP CERAMIC CAP. F Z 0.1µF/25V or CHD1EZB0F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V
or
CHD1JZ30F104
CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V
or
CHD1EZ30F104
CHIP CERAMIC CAP. FZ Z 0.1µF/50V CHD1JZ3FZ104
C310 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C311 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL010
C312 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C313 ELECTROLYTIC CAP. 1µF/50V M H7 CE1JMASSL010
C314 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C315 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EKB0B104
CHIP CERAMIC CAP. B K 0.1µF/16V or CHD1CKB0B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/25V
or
CHD1EK30B104
CHIP CERAMIC CAP.(1608) B K 0.1µF/16V CHD1CK30B104
C316 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C317 CHIP CERAMIC CAP. F Z 1µF/10V or CHD1AZB0F105
CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C318 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMAVSL220
C319 CHIP CERAMIC CAP.(MELF) F Z 0.01µF/
16V or
CZM1CZB0F103
CHIP CERAMIC CAP.(MELF) F Z 0.01µF/
16V
CZM1CZ30F103
Ref. No. Mark Description Part No.
