Emerson EWD2004OM Supplement Service Manual

20040227 1-17-1 H9600CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a #
have special characteristics important to safety. Before
replacing any of these components, read carefully the
product safety notice in this service manual. Don't
degrade the safety of the product through improper ser-
vicing.
Comparison Chart of Models and Marks
Model Mark
DVC860E A
DVC840E B
DVC845E C
EWD2204 D
Ref. No. Mark Description Part No.
A1X A FRONT ASSEMBLY H9600UD 0VM204492
A1X B FRONT ASSEMBLY H9601UD 0VM204493
A1X C FRONT ASSEMBLY H9604UD 0VM204547
A1X D FRONT ASSEMBLY H9610UD 0VM204511
A2 TOP CASE H9600UD 0VM101340
A3 CHASSIS(D5) H9600UD 0VM000197
A8 A DOOR, CASSETTE H9600UD 0VM306647
A8 B,C DOOR, CASSETTE H9601UD 0VM416215
A8 D DOOR, CASSETTE H9610UD 0VM306694
A9 SPRING, DOOR H7220UD U15 0VM408617
A10# A LABEL, RATING(U) H9600UD or ----------
# A LABEL, RATING(D) H9600UD ----------
A10# B LABEL, RATING(U) H9601UD or ----------
# B LABEL, RATING(D) H9601UD ----------
A10# C LABEL, RATING(U) H9604UD or ----------
# C LABEL, RATING(D) H9604UD ----------
A10# D LABEL, RATING(U) H9610UD or ----------
# D LABEL, RATING(D) H9610UD ----------
A14 LABEL, BAR CODE HB400UD ----------
A14 A LABEL, BAR CODE H9600UD ----------
A14 B LABEL, BAR CODE H9601UD ----------
A14 C LABEL, BAR CODE H9604UD ----------
A14 D LABEL, BAR CODE H9610UD ----------
A18 A,B,C LABEL, TELEPHONE NUMBER
H5730UD(SYLVANIA)
----------
A18 D LABEL, TELEPHONE NUMBER
H7931UD(EMERSON)
----------
A19 D HOLDER, EAS(H9410UD) MAKER
NO.EM150DR
0VM415877
A22 CHASSIS FOOT H79P9JD 0VM412315
1B1 A DECK ASSEMBLY CZD013/VM2260 N2260FL
1B1 B,C,D DECK ASSEMBLY CZD013/VM2240 N2240FL
1B2 DVD MECHA(FG LESS) 0838 VCZL0500 N79F0HVM
2B2 TOP BRACKET H9600UD 0VM204470
2B3 RODER HOLDER H9600UD 0VM306676
2B16 TAPE, HIMELON H9206JD 0VM413956
2B40 PARTITION PLATE H9600UD 0VM306677
2L011 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L012 SCREW, S-TIGHT M3X6 BIND HEAD+ GBMS3060
2L021 SCREW, P-TIGHT 3X12 BIND HEAD+ GBMP3120
2L022 P-TIGHT SCREW 3X8 BIND + GBMP3080
2L041 SCREW, P-TIGHT 3X10 BIND HEAD+ GBEP3100
2L051 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L054 SCREW, P-TIGHT M3X6 BIND HEAD+ GBMP3060
2L071 SCREW, P-TIGHT M3X10 WASHER HEAD+ GCMP3100
2L091 SCREW, P-TIGHT M3X8 BIND HEAD+ GBCP3080
PACKING
S1 A GIFT BOX CARTCON H9600UD 0VM306773
S1 B GIFT BOX CARTON H9601UD 0VM306774
S1 C GIFT BOX CARTON H9604UD 0VM306777
S1 D GIFT BOX CARTON H9610UD 0VM306868
S2 STYROFOAM H9600UD 0VM204474
S3 UNIT, BAG E5500UD 0VM411683
ACCESSORIES
X1 A REMOTE CONTROL UNIT DVD 0364
VCZF05DD
NB101UD
X1 B,C,D REMOTE CONTROL UNIT DVD 0364
VCZF05DD
NB100UD
X2 DRY BATTERY R6P/2S or XB0M451T0001
DRY BATTERY ES-GR6M-C XB0M571GLP01
X3 RF CABLE 2.5C-2V WPZ0901TM002
X4 ACCESSORY BAG E5700UD 0VM415576
X5 AV CORD TSCKA-Y/RW100 or WPZ0102TM015
AV CORD RCA(M*2)TO RCA(M*2) WPZ0102LTE01
X20# A OWNER'S MANUAL H9600UD 0VMN04012
X20# B OWNER'S MANUAL H9601UD 0VMN04013
X20# C OWNER'S MANUAL H9604UD 0VMN04016
X20# D OWNER'S MANUAL H9610UD 0VMN04085
Ref. No. Mark Description Part No.
