Emerson EX4 User Manual

EX4-8
Emerson Climate Technologies GmbH www.emersonclimate.eu Date: 28.04.2020
Am Borsigturm 31 I 13507 Berlin I Germany EX4-8_OI_EN_DE_FR_ES_IT_RU_R08_865288.docx
Fig./ Рис. 1
Fig./ Рис. 2
Fig./ Рис. 3
Fig./ Рис. 5
Fig./ Рис. 4 (mm/ мм)
EX4/EX5/EX6/EX7 EX8
Fig./ Рис. 6
EXV
Ø A x Ø F(ODF)
B
C
D
E
H1
H2
EX4-I21
3/8" x 5/8"
8
45
55
11
113
25
EX4-M21
10 x 16 mm
8
45
55
11
113
25
EX5-U21
5/8" x 7/8" (16 x 22 mm)
11
55
65
16
113
25
EX6-I21
7/8" x 1-1/8"
16
65
75
19
113
25
EX6-M21
22 x 28 mm
16
65
75
19
113
25
EX7-I21
1-1/8" x 1-3/8"
20
78
83
20
158
42
EX7-M21
28 x 35 mm
20
78
83
20
158
42
EX8-M21
42 x 42 mm
20
80
80
20
200
56
EX8-U21
1-3/8” (35 mm) x 1-3/8” (35 mm)
20
80
80
20
200
56
EX8-I21
1-5/8” x 1-5/8”
20
80
80
20
200
56
EX4-U31
5/8" x 5/8" (16 x 16 mm)
11
55
55
11
113
25
EX5-U31
7/8" x 7/8" (22 x 22 mm)
16
65
65
16
113
25
EX6-I31
1-1/8" x 1-1/8"
19
75
75
19
113
25
EX6-M31
28 x 28 mm
19
75
75
19
113
25
EX7-U31
1-1/8" (35 mm) x 1-1/8” (35 mm)
23
83
83
23
158
42
