Emerson FB1100 Termination Board Field Replacement Guide

FB1100/FB1200 Flow Computer Termination Board Field Replacement Guide
D301820X012
March 2018
3
Notes
 Refer to the tables below for the correct field replacement part number.
Termination Boards
UL Field Replacement Kit Part Number
Termination Board (used with 6-
connector pluggable terminal blocks)
399185-01-1
Termination Board (used with 8-
connector pluggable terminal blocks on
any FB1200 Flow Computer which has a
6-channel expansion I/O board)
400216010-KIT
Terminal Blocks/Plugs
UL Field Replacement Kit Part Number
6-connector pluggable terminal blocks
(pack of 4)
395791014-KIT
8-connector pluggable terminal blocks
(pack of 4) – (Used with any FB1200 Flow
Computer which has a 6-channel
expansion I/O board)
395803000-KIT
 Ambient Temperature Range
May be used up to a maximum ambient temperature of 80C and a
minimum ambient temperature of -40C; see end product data plate for
ambient temperature.
 Required Tools
Tool
Usage
#1 Phillips-head screwdriver
For screws on HMI module and other
boards
#2 Phillips-head screwdriver
For screws on other modules and boards
3/32 inch flat head screwdriver
For 3.81 mm pitch terminal block
connections
1/8 inch flat-head screwdriver
For 5.08 mm pitch terminal block
connections
3 mm hexagonal torque wrench with
range covering 10 to 12 in-lbs (1.1 to 1.4
N m)
For end cap retaining clamps (if used)
 Electrical Ratings:
Input Voltage:
5.7-30Vdc, 10 Watts Max
I/O Ratings (FB1200 Flow Computer):
4 Digital Outputs:
2 Analog Outputs:
0.5A, 24Vdc
4-20mA
