Instruction Manual
D101642X012
ENVIRO-SEAL Sliding-Stem Valves
July 2017
10
Figure 7. ENVIRO-SEAL Graphite ULF Packing for Fisher easy-e Valves
39B4612-A
PACKING FLANGE
STUD
PACKING NUT
PACKING RING
PACKING RING
PACKING BOX RING
ANTI-SEIZE LUBRICANT
SPRING PACK ASSEMBLY
GUIDE BUSHING
PACKING WASHER
GUIDE BUSHING
