Instruction Manual
D101642X012
ENVIRO-SEAL Sliding-Stem Valves
July 2017
9
Figure 5. PTFE Sliding-Stem ENVIRO-SEAL Packing for Fisher easy-e Valves
A6146-1
ANTI-SEIZE LUBRICANT
STUD
LANTERN RING
PACKING SET
PACKING BOX RING
PACKING NUT
PACKING FLANGE
ANTI-EXTRUSION WASHERS
LOWER WIPER
SPRING PACK ASSEMBLY
(KEY 217)
217
Figure 6. ENVIRO-SEAL Duplex Packing for Fisher easy-e Valves
200
212
201
215
216
207
209
211
217
207
207
207
214
213
PACKING NUT
PACKING FLANGE
PACKING WASHER
SPRING PACK ASSEMBLY
ANTI-SEIZE LUBRICANT
STUD
LANTERN RING
PACKING SET
PACKING BOX RING
GUIDE BUSHING
PACKING RING
GUIDE BUSHING
GUIDE BUSHING
GUIDE BUSHING
24B9310
A6722
