Emerson Fisher Fieldvue DVC6010f User Manual

DVC6000f Series
March 2006
11-4
Key Description Part Number
Relay
24 Relay Assembly, includes shroud, relay seal,
and mounting screws
Standard
Double-acting and single-acting direct 38B5786X052
Single-acting reverse 38B5786X062
Double-acting and single-acting
direct (low bleed) 38B5786X072
Extreme Temperature option
(fluorosilicone elastomers)
Double-acting and single-acting direct 38B5786X032
Single-acting reverse 38B5786X042
Terminal Box
4 Terminal Box Cap,
Aluminum 38B7714X012
Stainless Steel GB0108X0012
34* O-ring
(1,8)
36* O-ring
(1,8)
44 Wire Retainer, pl stl
(2)
(6 req’d) (not shown)
58 Set Screw, hex socket, SST
(2)
62 Pipe Plug, hex hd,
Aluminum 1H5137X0012
Stainless Steel 1H5137X0032
72 Cap Screw, hex socket, SST
(2)
164 Terminal Box Assembly
(8)
268 FIELDBUS Label
PWB Assembly
Note
Contact your Emerson Process
Management sales office for PWB
Assembly FS Numbers.
50* PWB Assembly
Standard Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance DIagnostic
Fieldbus Control
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
Fieldbus Logic
Fieldbus Diagnostics
Advanced Diagnostics
Performance Diagnostics
Key Description Part Number
Pressure Gauges, Pipe Plugs, or Tire
Valve Assemblies
47* Pressure Gauge, nickel-plated brass case, brass connection
Double-acting (3 req’d); Single-acting (2 req’d)
PSI/MPA Gauge Scale
To 60 PSI, 0.4 MPa 18B7713X042
To 160 PSI, 1.1 MPa 18B7713X022
PSI/bar Gauge Scale
To 60 PSI, 4 bar 18B7713X032
To 160 PSI, 11 bar 18B7713X012
66 Pipe Plug, hex hd
For Double-acting and single acting direct w/gauges
(none req’d)
For Single-acting reverse w/gauges (1 req’d)
Plated steel 1D829328982
SST 1D8293X0012
For all units w/o gauges (3 req’d)
Plated steel 1D829328982
SST 1D8293X0012
67 Tire Valve Assembly (3 req’d) 1N908899012
236 Screen
For single-acting direct units only 18B9610X012
Feedback Parts
Common Feedback Parts
80 Cap Screw, hex socket, SST
(2)
81 Square Nut, SST
(2)
223* Potentiometer/Bushing Assy
Standard
For DVC6010f, DVC6010fS, DVC6020f,
and DVC6020fS 18B9576X012
For DVC6030f and DVC6030fS 17B4030X032
For DVC6015 and DVC6025 19B6834X012
For DVC6035 19B6835X012
Extreme Temperature option (fluorosilicone elastomers)
For DVC6010f, DVC6010fS, DVC6020f and
DVC6020fS GE01028X012
For DVC6030f & DVC6030fS GE01027X012
163 Plain Washer, SST
(2)
11
* Recommended spare
1. Available in the Elastomer Spare Parts Kit
2. Available in the Small Hardware Spare Parts Kit
8. Available in the Terminal Box Kit
