Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
August 2015
44
CSA
Ordinary Locations Approval
Complies with general electrical safety CAN/CSAC22.2 No. 6101012004
SELV, conduit connected, Enclosure Type 4X, IP66, Installation Category I, Pollution Degree 4
DVC6200 Series (HART HW1, F
OUNDATION fieldbus, PROFIBUS)
Rated Input 9-30 VDC, 4-20 mA
-52_C to + 80_C Ambient
DVC6205 (HART HW1, F
OUNDATION fieldbus, PROFIBUS) DVC6215 Remote Mount
Rated Input 9-30 VDC, 4-20 mA Rated Input 10 VDC max, 3.5 mA max
Outputs 0-9.6 VDC, 0-3.5 mA -52 to 125_C Ambient
-52_C to + 80_C Ambient
Explosion-proof and Dust Ignition-proof
DVC6200 and DVC6205 Series (HART HW1 & HW2, SIS, FOUNDATION FIELDBUS, PROFIBUS)
Class I, Division 1, Groups B,C,D ; Class I, Division 2, Groups A,B,C,D
Class II, Division 1, Groups E,F,G ; Class II, Division 2, Groups F,G
Class III, Division 1
Ex d IIC
Ex nC IIC
Type 4X, IP66
Single Seal Device (HART HW2 and SIS pending)
Rated input 30 Vmax, 20 mA
- 52_C < Ambient < + 80_C
Max inlet pressure 10 bar (145 psig) (air or natural gas)
Temperature Code: T6 (Tamb ≤ 75_C), T5 (Tamb ≤ 80_C)
DVC6215 Remote Mount
Class I, Division 1, Groups A,B,C,D ; Class I, Division 2, Groups A,B,C,D
Class II, Division 1, Groups E,F,G ; Class II, Division 2, Groups F,G
Class III
Ex d IIC
Ex nA IIC
Type 4X, IP66
Rated input 30 Vmax, 20 mA
- 52_C < Ambient < + 125_C
Temperature Code: T6 (Tamb ≤ 75_ C), T5 (Tamb ≤ 90_C), T4 (Tamb ≤ 125_C)
