Emerson Fisher FIELDVUE DVC6200 HW1 User Manual

Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
August 2015
49
1 SEE NOTES IN FIGURE 42
CSA
APPROVED
ENTITY
DEVICE
HAZARDOUS LOCATION
NON‐HAZARDOUS LOCATION
CLASS I, ZONE 0, GROUP IIC
CLASS I, DIV 1, GROUPS ABCD
CLASS II, DIV 1, GROUPS EFG
CLASS III
Vmax = 30 VDC
Imax = 226 mA
Ci = 50 nF
Li = 0.55 mH
Pi = 1.4 W
CSA APPROVED
BARRIER
NON‐HAZARDOUS LOCATION
HAZARDOUS LOCATION
ENTITY FIELDBUS LOOP
CSA APPROVED
FISCO BARRIER
CSA APPROVED
FISCO
TERMINATOR
CSA
APPROVED
FISCO DEVICE
FISCO LOOP
1 NOTE 1, 3, 4, 5, 6
NOTE 1, 3 1
NOTE 7 1
1 NOTE 2, 3, 4, 5, 6
NOTE 2, 3 1
GE42818 Sheet 10, Rev. D
T CODE T (amb)
T4 ≤ 80_C
T6 ≤ 62_C
T5 ≤ 77_C
Figure 41. CSA Loop Schematics FIELDVUE DVC6205f, DVC6205p, and DVC6215
NOTE 1 1
DVC6205f, DVC6205p
Voc = 24 VDC
Isc = 17.5 mA
Ca = 121 nF
La = 100 mH
Po = 105 mW
Vmax = 24 VDC
Imax = 380 mA
Ci = 5 nF
Li = 0 mH
Pi = 1.4 W
DVC6215
Vmax = 30 VDC
Imax = 226 mA
Ci = 50 nF
Li = 0.55 mH
Pi = 1.4 W
Vmax = 17.5 VDC
Imax = 380 mA
Ci = 5 nF
Li = 0 mH
Pi = 5.32 W
DVC6215
CLASS I, ZONE 0, GROUP IIC
CLASS I, DIV 1, GROUPS ABCD
CLASS II, DIV 1, GROUPS EFG
CLASS III
DVC6205f, DVC6205p
Voc = 17.5 VDC
Isc = 17.5 mA
Ca = 121 nF
La = 100 mH
Po = 105 mW
NOTE 2 1
CLASS I, ZONE 0, GROUP IIC
CLASS I, DIV 1, GROUPS ABCD
CLASS II, DIV 1, GROUPS EFG
CLASS III
CLASS I, ZONE 0, GROUP IIC
CLASS I, DIV 1, GROUPS ABCD
CLASS II, DIV 1, GROUPS EFG
CLASS III
T CODE T (amb)
T4 ≤ 125_C
T6 ≤ 75_C
T5 ≤ 90C
T CODE T (amb)
T4 ≤ 80_C
T6 ≤ 62_C
T5 ≤ 77_C
T CODE T (amb)
T4 ≤ 125_C
T6 ≤ 75_C
T5 ≤ 90C
GE42818 Sheet 9, Rev. D
