Emerson Fisher FIELDVUE DVC6200 Series - Page 10

Instruction Manual Supplement
D104205X012
DVC6200 Digital Valve Controllers
November 2020
10
Ui = 30 VDC
Ii = 226 mA
Pi = 1.4 W
Ci = 5 nF
Li = 0.55 mH
ZONE 0, Ex ia IIC
ZONE 0, Ex ia IIB
ZONE 20, Ex ia IIIC
LOOP TERMINALS
AUX TERMINALS
Ex ia IIC
LOOP TERMINALS
Ex ia IIC
LOOP TERMINALS
Ex ia IIC
LOOP TERMINALS
Ex ia IIB
Ui = 30 VDC
Ii = 101 mA
Pi = 757 mW
Ci = 5 nF
Li = 0.55 mH
Ui = 24.3 VDC
Ii = 169 mA
Pi = 1.026 W
Ci = 5 nF
Li = 0.55 mH
Ui = 30 VDC
Ii = 226 mA
Pi = 1.4 W
Ci = 5 nF
Li = 0.55 mH
Uo = 30 VDC
Io = 101 mA
Po = 757 mW
Co = 64 nF
Lo = 5.34 mH
Not Used
AUX TERMINALS
Uo = 24.3 VDC
Io = 169 mA
Po = 1.026 W
Co = 118 nF
Lo = 0.30 mH
AUX TERMINALS
Uo = 30 VDC
Io = 226 mA
Po = 1.4 W
Co = 558 nF
Lo = 3.76 mH
DVC6200, DVC6200S
ATEX APPROVED BARRIER
NOTE 1, 3, 4 1
NOTE 5 1
AUX TERMINALS
HAZARDOUS LOCATION NON‐HAZARDOUS LOCATION
Figure 5. ATEX Loop Schematic—FIELDVUE DVC6200 HW1
ZONE 0
Ex ia IIC or Ex ia IIB
DVC6200
DVC6200S
ZONE 20
Ex ia IIIC
MAX
SURFACE
TEMP
T89_C
T85_C
T AMB
≤ 80_C
≤ 76_C
T AMB
≤ 80_C
≤ 75_C
T CODE
T5
T6
TYPE
1 SEE NOTES IN FIGURE 6
GE60771 Sheet 3, Rev. D
