Quick Start Guide
D103556X012
DVC6200 Digital Valve Controllers
August 2015
51
FM
Explosion-proof, Dust-Ignition proof, Non-Incendive, Suitable for Use
DVC6200 and DVC6205 Series (HART HW1 & HW2, SIS, FOUNDATION FIELDBUS, PROFIBUS)
XP: Class I, Division 1, Groups B,C,D
DIP: Class II, III, Division 1, Groups E,F,G
NI: Class I, Division 2, Groups A,B,C,D
S: Class II, III, Division 2, Groups F,G
T5 Ta = 80°C, T6 Ta = 75°C
Type 4X, IP66
DVC6215 Remote Mount
XP: Class I, Division 1, Groups A,B,C,D
DIP: Class II, III, Division 1, Groups E,F,G
NI: Class I, Division 2, Groups A,B,C,D
S: Class II, III, Division 2, Groups F,G
Ta = 125°C, T5 Ta = 90°C, T6 Ta = 75°C
Type 4X, IP66
Intrinsically Safe
IS Class I, II, III, Division 1, Groups A,B,C,D,E,F,G
Type 4X, IP66
Intrinsically safe when connected per control drawing GE42819, as shown in the following figures
DVC6200 HW1 figure 43 and 48...........................................
DVC6200 HW2 and DVC6200 SIS figure 44 and 48...........................
DVC6205, DVC6205 SIS, and DVC6215 Remote Mount figure 45 and 48........
DVC6200f and DVC6200p figure 46 and 48.................................
DVC6205f, DVC6205p, and DVC6215 Remote Mount figure 47 and 48.........
Special Conditions of Safe Use
D When product is used with natural gas as the pneumatic medium, the maximum working pressure of the natural
gas supply shall be limited to 10 bar (145 psi).
D When product is used with natural gas as the pneumatic medium the product shall not be permitted in a Class I,
Division 2, Group A, B, C, D location without the proper venting installation per the manufacturer's instruction
manual.
D The apparatus enclosure contains aluminum and is considered to constitute a potential risk of ignition by impact
or friction. Care must be taken into account during installation and use to prevent impact or friction.
D Part of the enclosure is constructed from plastic. To prevent the risk of electrostatic sparking the plastic surface
should only be cleaned with a damp cloth.
