Instruction Manual
D103031X012
D2 FloPro Valve
June 2011
11
Figure 4. Packing and Belleville Spring Stacking Order
ANTI-EXTRUSION
WASHER (KEY 12)
PACKING RING
(KEY 11)
FEMALE PACKING
ADAPTER (KEY 11)
PACKING SPACER
(KEY 10)
BELLEVILLE
SPRINGS (KEY 9)
MALE PACKING
ADAPTER (KEY 11)
ANTI-EXTRUSION
WASHER (KEY 12)
VALVE
PLUG (KEY 3)
PACKING RETAINER
(KEY 8)
UNTIGHTENED,
NOTE THE GAP
FULLY TIGHTENED,
NO GAP
BELLEVILLE SPRINGS FULLY ENCLOSED BY
THE PACKING RETAINER
VALVE PLUG, BELLEVILLE SPRINGS, AND PACKING RETAINER
CORRECTLY INSTALLED AND TIGHTENED
FLUSH
