The default value of 1.500 will produce 10 V output on the analog output (terminal 6)
when the feedback is at 100 % (Pr 54 Flux Feedback).
This parameter must be set to the same value as Pr 6.11 on Mentor II when used with
Mentor II. It defines the full scale current in amps.
In stand alone mode, setting this parameter will instruct the field controller to set-up its
flux loop gains automatically. If any voltage is detected on the armature voltage input
during the autotune then the unit will trip.
At the end of the autotune routine, Pr 77 is set to 0 (off) when Pr 81 = 0. If Pr 81 = 1,
then the controller remains in the enabled condition as controlled by the digital input.
This parameter sets the level at which field loss is detected and operates the fail relay in
Mentor II and standalone mode 100 % level = 150 % flux. 10 % flux / 1.5 = 6.7 the same
level as FXM5.
07 Field flux output scaling
Coding
Bit FI Txt VM DP ND US RW BU PS
3111
Range 0.000 to 4.000
Default 1.500
Update rate Background
11 Field current feedback scaling
Coding
Bit FI Txt VM DP ND US RW BU PS
111
Range 0 to 20
Default 10
Update rate Background
This parameter must be set before Pr 78 is selected for Mentor II mode. If already in
Mentor II mode [Pr 78 = 2.H (2) or 2.F (3)] a power cycle is required before the new
values will take effect.
NOTE
12 Autotune
Coding
Bit FI Txt VM DP ND US RW BU PS
11
Range OFF (0) or On (1)
Default OFF (0)
Update rate Background read
25 FXMP25 OK flux level
Coding
Bit FI Txt VM DP ND US RW BU PS
1111
Range 0.0 to 100.0 %
Default 6.7 %
Update rate 16 ms
