The programmable value of the armature back emf or armature voltage (standalone
mode), in volts, at which the field begins to weaken. Defined as the voltage at which
base speed is reached.
The calculated voltage being generated on the field output terminals. Calculated from
applied mains voltage and firing angle.
Gains used during field weakening. Setting these too high could cause instability during
field weakening.
Gains used during field weakening. Setting these too high could cause instability during
field weakening.
When this parameter is set to OFF (0) the field controller operates with the field
weakening voltage loop. When set to On (1) the flux level is determined by reference on
terminal 3.
59 Field weakening voltage set point
Coding
Bit FI Txt VM DP ND US RW BU PS
111
Range 0 to 750 V
Default Eur: 400, USA: 480
Update rate Background write
60 Field output voltage
Coding
Bit FI Txt VM DP ND US RW BU PS
11
Range 0 to 500 V
Update rate Background write
62 Field weakening loop P gain
Coding
Bit FI Txt VM DP ND US RW BU PS
2111
Range 0.00 to 99.99
Default 0.40
Update rate Background read
63 Field weakening loop I gain
Coding
Bit FI Txt VM DP ND US RW BU PS
2111
Range 0.00 to 99.99
Default 5.00
Update rate Background read
64 External flux reference select
Coding
Bit FI Txt VM DP ND US RW BU PS
11
Range OFF (0) to On (1)
Default OFF (0)
Update rate Background read
