Emerson Keystone User Manual

6
DN900 - 1000
DN1050 - 1600 (PN10)
DN1600 (PN16) - 2400
PARTS LIST
Part Name
1 Body
2 Disc
3 Driving (top) shaft
4 Bottom shaft
5 Seat
6 Bearing
7 Nut + spring washer
8 Cover
9 O-ring seal
10 Thru bolt
11 Snap ring
12 Screw + washer
13 Key
14 Bushing
PARTS LIST
Part Name
1 Body
2 Disc
3 Driving (top) shaft
4 Bottom shaft
5 Seat
6 Bearing
7 Nut + spring washer
8 Cover
9 O-ring seal
10 Thru bolt
11 Snap ring
12 Screw + washer
13 Key
14 Bushing
KEYSTONE BUTTERFLY VALVES PARASEAL
InstallatIon and maIntenance InstructIons
PARTS LIST
Part Name
1 Body
2 Disc
3 Driving (top) shaft
4 Bottom shaft
5 Seat
6 Bearing
7 Nut + spring washer
8 Cover
9 O-ring seal
10 Thru bolt
11 Snap ring
12 Screw + washer
13 Key
14 Bushing
