4-1 A8AN5DC
CABINET DISASSEMBLY INSTRUCTIONS
1. Disassembly Flowchart
This flowchart indicates the disassembly steps for the
cabinet parts, and the CBA in order to gain access to
item(s) to be serviced. When reassembling, follow the
steps in reverse order. Bend, route and dress the
cables as they were.
2. Disassembly Method
Note:
(1) Order of steps in procedure. When reassembling,
follow the steps in reverse order. These numbers
are also used as the Identification (location) No. of
parts in figures.
(2) Parts to be removed or installed.
(3) Fig. No. showing procedure of part location
(4) Identification of parts to be removed, unhooked,
unlocked, released, unplugged, unclamped, or
desoldered.
N = Nut, L = Locking Tab, S = Screw,
CN = Connector
* = Unhook, Unlock, Release, Unplug, or Desolder
e.g. 2(S-2) = two Screws (S-2),
2(L-2) = two Locking Tabs (L-2)
(5) Refer to the following "Reference Notes in the
Table."
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
[1]
Stand
Cover
D1 2(S-1) ---
[2] Stand Neck D1 2(S-2) ---
[3]
Fix Stand
Holder
D1 2(S-3) ---
[4]
Rear
Cabinet
D1 5(S-4), 4(S-5) ---
[6] Digital Main
CBA Unit
[11] IR Sensor CBA
[1] Stand Cover
[2] Stand Neck
[4] Rear Cabinet
[12] Function CBA
[14] Speaker(s)
[3] Fix Stand Holder
[5] Shield Box
[15] Front Cabinet
[8] Power Supply
CBA
[7] Tuner Holder
[10] Inverter CBA
[9] Junction CBA
[13] LCD Module
Assembly
[5] Shield Box
D2
D3
2(S-6), 2(S-7), 4(S-8),
*CN3601, *CN3701,
*CN3704, *CN4501,
*CN4502
---
[6]
Digital Main
CBA Unit
D2
D3
--------------- ---
[7]
Tuner
Holder
D2 (S-9) ---
[8]
Power
Supply
CBA
D2
D3
3(S-10), *CN102,
*CN306, *CN309
---
[9]
Junction
CBA
D2
D3
*CN403B ---
[10]
Inverter
CBA
D2
D3
4(S-11), *CN401,
*CN402, *CN451
---
[11]
IR Sensor
CBA
D2
D3
*CL101B ---
[12]
Function
CBA
D2
D3
--------------- ---
[13]
LCD
Module
Assembly
D2 --------------- ---
[14] Speaker(s) D2 4(S-12) ---
[15]
Front
Cabinet
D2 --------------- ---
(1)
(2)
(3)
(4)
(5)
Step/
Loc.
No.
Part
Removal
Fig.
No.
Remove/*Unhook/
Unlock/Release/
Unplug/Unclamp/
Desolder
Note
