Emerson LC195EM9 B Service Manual

20080422 12-1 A8AN5CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTE: Parts that are not assigned part numbers
(---------) are not available.
Ref. No. Description Part No.
A1 FRONT CABINET A8AN1UH 1EM122733
A3 CONTROL PLATE A8AN0UH 1EM324757
A4 REAR CABINET A8AN1UH 1EM122734
A5 DECORATION PLATE A8AN1UH 1EM222383
A6# RATING LABEL A8AN5UH ----------
A7 FUNCTION KNOB A8CN0FP 1EM222143
A9 STAND COVER A8AN1UH 1EM222423
A10 CONNECTOR CAP A8AN0UH 1EM426557
A11 SENSOR LED LENS A8CN0FP 1EM323959
A12 STAND RUBBER FOOT A8AN0UH 1EM426377
A24 STAND NECK A8AN1UH 1EM324477
A26 LOGO LABEL A8AN1UH ----------
B3 WALL MOUNT BRACKET A84N0UH 1EM323797
B8 SHIELD BOX A8AN1UH 1EM324439
B14 FIX STAND HOLDER A8AN0UH 1EM323938
B17 SEPARATION SHEET A8AN0UH 1EM324520
B36 GASKET A8AF0UH 1EM425861
B38 TUNER HOLDER A8AN0UH 1EM324097
CL4501 WIRE ASSEMBLY 55PIN WX1A8CN0-007 WX1A8CN0-007
CL4502 WIRE ASSEMBLY 55PIN WX1A8CN0-007 WX1A8CN0-007
L3 SCREW P-TIGHT 3X10 BIND HEAD+ GBHP3100
L5 SCREW P-TIGHT M4X18 BIND HEAD+ GBHP4180
L10 SCREW S-TIGHT M3X6 BIND HEAD+ GBJS3060
L11 SCREW S-TIGHT M3X8 BIND HEAD+ GBHS3080
L17 DOUBLE SEMS SCREW M4X9 + BLACK
L0130UA
0EM408146A
L28 HEX SCREW #4-40 7MM 1EM422042
L30 SCREW P-TIGHT M3X10 BIND HEAD+ GBJP3100
LCD1 LCD MODULE 19INCH WIDE CMO 19INCH
WXGA
UG190XF
SP801 SPEAKER MAGNETIC S0306N01 DSD0806XQ001
SP802 SPEAKER MAGNETIC S0306N01 DSD0806XQ001
PACKING
S1 CARTON A8AN1UH 1EM426480
S2 STYROFOAM TOP A8AN0UH 1EM022565
S3 STYROFOAM BTM A8AN0UH 1EM022566
S4 SET BAG A81N0UH 1EM323958
S5 SERIAL NO. LABEL L9750UA ----------
S16 STAND BAG A81N0UH 1EM425888
ACCESSORIES
X1 BAG POLYETHYLENE 235X365XT0.03 0EM408420A
X2# OWNERS MANUAL A8AN1UH 1EMN23319
X3 REMOTE CONTROL NF606UD NF606UD NF606UD
X4 DRY BATTERY(SUNRISE) R6SSE/2S XB0M451MS002
X14 FCC ADDENDUM SHEET A8AF1UH 1EMN23659

Emerson LC195EM9 B Specifications

General

Brand	Emerson
Model	LC195EM9 B
Category	Monitor
Language	English
