Emerson LC195EM9 B Service Manual

20080422 13-1 A8AN5EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read
carefully the product safety notice in this service
manual. Don't degrade the safety of the product
through improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Tolerance of Capacitors and Resistors are noted
with the following symbols.
DIGITAL MAIN CBA UNIT
MPS CBA
POWER SUPPLY CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DIGITAL MAIN CBA UNIT 1ESA17675
Ref. No. Description Part No.
MPS CBA
Consists of the following
1ESA17385
POWER SUPPLY CBA(MPS-1)
FUNCTION CBA(MPS-2)
IR SENSOR CBA(MPS-3)
----------
----------
----------
Ref. No. Description Part No.
POWER SUPPLY CBA(MPS-1)
Consists of the following:
----------
CAPACITORS
C1 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C2 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C3 CHIP CERAMIC CAP.(1608) CH J 22pF/50V CHD1JJ3CH220
C4 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C8 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C9 CHIP CERAMIC CAP.(1608) F Z 0.1µF/50V CHD1JZ30F104
C11 CHIP CERAMIC CAP. CH J 220pF/50V CHD1JJ3CH221
C12 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C13 ELECTROLYTIC CAP. 10µF/50V M H7 CE1JMAVSL100
C14 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C15 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C17 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C18 ELECTROLYTIC CAP. 330µF/10V M CE1AMASDL331
C19 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C21 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C22 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C23 CHIP CERAMIC CAP.(1608) CH J 1000pF/50V CHD1JJ3CH102
C501 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL1R0
C601 CAP ELE LT 270µF/200V/M/85 CA2D271V8005
C602 CERAMIC CAP. R K 680pF/2KV(HR) CCD3DKA0R681
C603 POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J
CA2A102DT018
C604 POLYESTER FILM CAP. (PB FREE) 0.033µF/
100V J
CA2A333DT018
C605 POLYESTER FILM CAP. (PB FREE) 0.001µF/
100V J
CA2A102DT018
C607# CAP CERAMIC 4700pF/250V/M/KX CA2E472MR101
C610 POLYESTER FILM CAP. (PB FREE) 0.082µF/
100V J
CA2A823DT018
C611# METALIZED FILM CAP. 0.47µF/250V CT2E474MS037
C633 ELECTROLYTIC CAP. 2200µF/25V M CE1EMZNDL222
C634 ELECTROLYTIC CAP 3300µF/10V CE1AMZNDL332
C635 POLYESTER FILM CAP. (PB FREE) 0.0022µF/
100V J
CA2A222DT018
C636 CERAMIC CAP. B K 1500pF/1KV CCD3AKP0B152
C638 ELECTROLYTIC CAP. 470µF/25V M CE1EMZADL471
C639 ELECTROLYTIC CAP 330µF/50V M CE1JMZADL331
C642 CAP ELE STD-85 4700µF 6.3V SL CE0KMZNDL472
C643 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C644 CHIP CERAMIC CAP.(1608) B K 0.1µF/50V CHD1JK30B104
C647 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C650 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C651 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C652 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C653 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C654 ELECTROLYTIC CAP. 1000µF/10V M CE1AMASDL102
C655 ELECTROLYTIC CAP. 470µF/10V M CE1AMASDL471
C660 ELECTROLYTIC CAP. 22µF/50V M(105C) CE1JMASTH220
C663 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C664 ELECTROLYTIC CAP 3300µF/6.3V M CE0KMZNDL332
C666 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C701 ELECTROLYTIC CAP. 100µF/10V M CE1AMASDL101
C702 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C703 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C704 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C705 CHIP CERAMIC CAP. B K 470pF/50V CHD1JK30B471
C706 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C707 CHIP CERAMIC CAP. B K 470pF/50V CHD1JK30B471
C708 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C709 CHIP CERAMIC CAP.(1608) CH J 68pF/50V CHD1JJ3CH680
C712 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C713 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C714 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C801 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C802 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C7201 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7202 PCB JUMPER D0.6-P5.0 JW5.0T
C7204 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C7301 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7302 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7303 CHIP CERAMIC CAP.(1608) F Z 0.1µF/25V CHD1EZ30F104
C7304 ELECTROLYTIC CAP. 100µF/16V M CE1CMASDL101
C7307 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C7308 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C7515 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C7516 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C7602 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C7605 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C7615 ELECTROLYTIC CAP. 4.7µF/50V M CE1JMASDL4R7
C7618 ELECTROLYTIC CAP. 4.7µF/50V M H7 CE1JMAVSL4R7
C7701 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7702 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7709 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
C7710 CHIP CERAMIC CAP. F Z 0.47µF/16V CHD1CZ30F474
C7714 CHIP CERAMIC CAP.(1608) CH J 100pF/50V CHD1JJ3CH101
Ref. No. Description Part No.
