Emerson LC195EM9 B Service Manual

20080422 13-2 A8AN5EL
C7715 CHIP CERAMIC CAP.(1608) B K 0.047µF/50V CHD1JK30B473
C7729 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7730 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C7733 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7734 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C7738 CHIP CERAMIC CAP. CH J 39pF/50V CHD1JJ3CH390
C7739 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
C7804 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
C7805 ELECTROLYTIC CAP. 220µF/16V M H7 CE1CMASSL221
C7806 ELECTROLYTIC CAP. 220µF/16V M H7 CE1CMASSL221
C7810 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7811 CHIP CERAMIC CAP. F Z 1µF/10V CHD1AZ30F105
C7813 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C7814 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C7817 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C7818 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
C7819 CHIP CERAMIC CAP.(1608) B K 3300pF/50V CHD1JK30B332
CONNECTORS
CN301 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN302 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN303 TWG CONNECTOR 23P TWG-P23P-A1 J3TWA23TG001
CN306 WIRE ASSEMBLY SPEAKER 2PIN 2PIN /95MM WX1A8AN0-003
CN309 242 SERIES CONNECTOR 224202112W1 J322C12TG001
DIODES
D2 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D3 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D502 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D503 DIODE FR104-B NDLZ000FR104
D504 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D506 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D507 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D508 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D509 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D510 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D511 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D513 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D514 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D602# ZENER DIODE MTZJT-7739B QDTB00MTZJ39
D603 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D604# ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D606 ZENER DIODE MTZJT-774.3B QDTB0MTZJ4R3
D607 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D609 DIODE 1N5397-B NDLZ001N5397
D610 DIODE 1N5397-B NDLZ001N5397
D611 DIODE 1N5397-B NDLZ001N5397
D612 DIODE 1N5397-B NDLZ001N5397
D631 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D632 SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D633 DIODE SCHOTTKY SB3150BH NDWZ00SB3150
D634 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D635# ZENER DIODE MTZJT-7727B QDTB00MTZJ27
D636 DIODE FR154 NDLZ000FR154
D637 DIODE FR154 NDLZ000FR154
D638 DIODE FR104-B NDLZ000FR104
D639 SCHOTTKY BARRIER DIODE SB140 NDQZ000SB140
D640 SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D641 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D642 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D644# DIODE 1ZC43(Q) QDLZ001ZC43Q
D645 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D646 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D647 SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
Ref. No. Description Part No.
D648 IC SHUNT REGULATOR KIA431-AT/P NSZBA0TJY036
D649 ZENER DIODE MTZJT-7733B QDTB00MTZJ33
D650 ZENER DIODE MTZJT-776.2C QDTC0MTZJ6R2
D651 RECTIFIER DIODE 1N4005 NDQZ001N4005
D652 ZENER DIODE MTZJT-7724B QDTB00MTZJ24
D653# ZENER DIODE MTZJT-7736B QDTB00MTZJ36
D654 DIODE FR154 NDLZ000FR154
D655 ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D656 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D657 DIODE FR154 NDLZ000FR154
D658 ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D660# ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D661 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D662 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D663 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D668 PCB JUMPER D0.6-P5.0 JW5.0T
D669 SCHOTTKY BARRIER DIODE SB160 NDWZ000SB160
D670 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D671 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D676 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D801 ZENER DIODE MTZJT-7710B QDTB00MTZJ10
D7005 ZENER DIODE MTZJT-7716B QDTB00MTZJ16
D7006 ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D7007 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D7801 ZENER DIODE MTZJT-7715B QDTB00MTZJ15
D7802 ZENER DIODE MTZJT-7715B QDTB00MTZJ15
D7803 ZENER DIODE MTZJT-773.3B QDTB0MTZJ3R3
D7804 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC603# PHOTO COUPLER LTV817MCF NPECLTV817MF
IC637 IC LD1117V NSZBA0SSS046
IC701 IC(AUDIO D/A) PCM1782DBQR NSZBA0TTY192
IC702 IC OP AMP NJM4558M(TE1)-#ZZZB QSZBA0TJR089
IC7301 IC SWITCHING TC4052BF(ELNF) QSZBA0TTS162
IC7304 IC AUDIO SA7412 NSZBA0SQ0007
COILS
L1 CHOKE COIL 22µF-K LLBD00PKV021
L601# LINE FILTER 5.0MH 6Y075 LLBG00ZKT004
L7804 PCB JUMPER D0.6-P5.0 JW5.0T
L7805 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q3 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q4 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q5 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q501 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q502 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q601# FET MOS 2SK3563(Q) QFWZ2SK3563Q
Q602# TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q631 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q632 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q633 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q634 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q637 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Q638 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Q639 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q645 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Q646 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q650 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q671 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q801 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Ref. No. Description Part No.
