1-1 A8AN4SP
SPECIFICATIONS
< TUNER / NTSC >
ANT. Input ---------------------- 75 Unbal., F type
< TUNER / ATSC >
< LCD PANEL >
< VIDEO >
Description Condition Unit Nominal Limit
1. AFT Pull-In Range --- MHz ±2.3 ±2.1
2. Syncronizing Sens.
TV.ch.4
CA.ch.31
CA.ch.87
dBµ
dBµ
dBµ
---
---
---
20
20
23
Description Condition Unit Nominal Limit
1. Received Freq. Range (-28dBm) --- kHz --- ±100
2. ATSC Dynamic Range (min / max)
ch.4
ch.10
ch.41
dBm
dBm
dBm
---
---
---
-76/0
-76/0
-74/+4
Description Condition Unit Nominal Limit
1. Native Pixel Resolusion
Horizontal
Vertical
pixels
pixels
1440
900
---
---
2. Brightness (w / filter) --- cd/m
2
220 ---
3. Viewing Angle
Horizontal
Vertical
°
°
-85 to 85
-80 to 80
---
---
Description Condition Unit Nominal Limit
1. Over Scan
Horizontal
Vertical
%
%
6
6
6±5
6±5
2. Color Temperature
---
x
y
°K 12000
0.272
0.278
---
±3%
±3%
3. Resolution (composite video)
Horizontal
Vertical
line
line
270
350
---
---
