Emerson LC195EM9 B Service Manual

20080422 13-3 A8AN5EL
Q7201 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q7301 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q7302 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
Q7303 CHIP TRANSISTOR KTC3875S-GR-RTK/P NQ14KTC3875S
RESISTORS
R7 CHIP RES. 1/10W J 150k Ω RRXAJR5Z0154
R8 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R11 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R12 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R13 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R14 CHIP RES. 1/10W J 220k Ω RRXAJR5Z0224
R16 CHIP RES. 1/10W J 750 Ω RRXAJR5Z0751
R17 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R18 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R19 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R20 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R21 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R22 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R24 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R25 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R26 CHIP RES. 1/10W J 82 Ω RRXAJR5Z0820
R106 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R107 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R108 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R109 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R303 PCB JUMPER D0.6-P5.0 JW5.0T
R501 PCB JUMPER D0.6-P5.0 JW5.0T
R502 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R504 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R505 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R506 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R507 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R521 PCB JUMPER D0.6-P5.0 JW5.0T
R523 CHIP RES. 1/10W F 36k Ω RRXAFR5H3602
R526 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R580 CHIP RES. 1/10W F 4.7k Ω RRXAFR5H4701
R581 CHIP RES. 1/10W F 4.7k Ω RRXAFR5H4701
R582 CHIP RES. 1/10W F 3.9k Ω RRXAFR5H3901
R583 CHIP RES. 1/10W F 3.9k Ω RRXAFR5H3901
R584 CHIP RES. 1/10W F 300 Ω RRXAFR5H3000
R585 CHIP RES. 1/10W F 300 Ω RRXAFR5H3000
R586 CHIP RES. 1/10W F 300 Ω RRXAFR5H3000
R587 CHIP RES. 1/10W F 300 Ω RRXAFR5H3000
R588 CHIP RES. 1/10W F 300 Ω RRXAFR5H3000
R601# METAL OXIDE FILM RES. 2W J 0.47 Ω RN02R47DP004
R602# GLASS GLAZE RES. 1/2W J 3.3M Ω RXX2JZLZ0335
R604 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R605 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R606 PCB JUMPER D0.6-P5.0 JW5.0T
R607 CARBON RES. 1/4W J 390k Ω RCX4JATZ0394
R608# CEMENT RES. 3W K 1.2 Ω RW031R2PG007
R609 CARBON RES. 1/4W J 3.9k Ω RCX4JATZ0392
R610 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R611 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R612 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R613 CARBON RES. 1/4W J 180 Ω RCX4JATZ0181
R620 METAL OXIDE FILM RES. 1W J 0.68 Ω RN01R68DP003
R622 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R627 METAL OXIDE FILM RES. 1W J 6.8 Ω RN016R8DP003
R628 METAL OXIDE FILM RES. 1W J 6.8 Ω RN016R8DP003
R629 METAL OXIDE FILM RES. 1W J 6.8 Ω RN016R8DP003
R631 METAL OXIDE FILM RES. 1W J 8.2 Ω RN018R2DP003
Ref. No. Description Part No.
R632 CHIP RES. 1/10W F 4.7k Ω RRXAFR5H4701
R634 CARBON RES. 1/4W J 6.8k Ω RCX4JATZ0682
R635 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R636 CHIP RES. 1/10W F 4.7k Ω RRXAFR5H4701
R637 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R638 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R639 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R640 CHIP RES. 1/10W F 2.2k Ω RRXAFR5H2201
R641 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R647 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R648 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R649 METAL OXIDE FILM RES. 1W J 680 Ω RN01681DP003
R651 CARBON RES. 1/4W J 3.3k Ω RCX4JATZ0332
R652 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273
R653 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R654 CARBON RES. 1/4W J 1.8k Ω RCX4JATZ0182
R655 CHIP RES. 1/10W F 1.0k Ω RRXAFR5H1001
R656 CARBON RES. 1/4W J 68 Ω RCX4JATZ0680
R658 CHIP RES. 1/10W F 620 Ω RRXAFR5H6200
R660 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R662 CHIP RES. 1/10W J 4.7k Ω RRXAJR5Z0472
R663 METAL OXIDE FILM RES. 2W J 0.47 Ω RN02R47DP004
R664 CHIP RES. 1/10W F 10k Ω RRXAFR5H1002
R666 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R667 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R668 CHIP RES. 1/10W F 3.3k Ω RRXAFR5H3301
R670 CARBON RES. 1/4W J 1k Ω RCX4JATZ0102
R671 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R673 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R674 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R675 CARBON RES. 1/4W J 47k Ω RCX4JATZ0473
R676 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R677 CARBON RES. 1/4W J 22k Ω RCX4JATZ0223
R684 CHIP RES. 1/10W F 820 Ω RRXAFR5H8200
R686 CHIP RES. 1/10W F 5.6k Ω RRXAFR5H5601
R687 CARBON RES. 1/4W J 12k Ω RCX4JATZ0123
R688 CARBON RES. 1/4W J 270 Ω RCX4JATZ0271
R689 CARBON RES. 1/4W J 8.2k Ω RCX4JATZ0822
R692 CARBON RES. 1/4W J 10k Ω RCX4JATZ0103
R701 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R702 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R703 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R704 CHIP RES. 1/10W J 47k Ω RRXAJR5Z0473
R705 CHIP RES. 1/10W J 30k Ω RRXAJR5Z0303
R706 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R710 CHIP RES. 1/10W J 33k Ω RRXAJR5Z0333
R713 CHIP RES. 1/10W J 30k Ω RRXAJR5Z0303
R714 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R717 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R718 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R720 CHIP RES. 1/10W J 33k Ω RRXAJR5Z0333
R803 CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R804 CARBON RES. 1/4W J 470 Ω RCX4JATZ0471
R7201 CHIP RES. 1/10W J 47 Ω RRXAJR5Z0470
R7202 CHIP RES. 1/10W J 24 Ω RRXAJR5Z0240
R7204 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7206 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7207 CHIP RES. 1/10W J 56 Ω RRXAJR5Z0560
R7301 PCB JUMPER D0.6-P5.0 JW5.0T
R7302 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7303 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7306 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R7307 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
Ref. No. Description Part No.
