Emerson LC195EM9 B Service Manual

20080422 13-4 A8AN5EL
FUNCTION CBA
IR SENSOR CBA
R7308 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7309 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R7311 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7312 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7313 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7315 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7316 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7317 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7318 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R7319 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7326 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R7327 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R7328 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7333 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7334 CARBON RES. 1/4W J 100k Ω RCX4JATZ0104
R7335 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R7515 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R7516 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R7517 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R7518 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R7601 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R7602 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R7604 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R7605 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R7613 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R7614 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R7616 CHIP RES. 1/10W J 39k Ω RRXAJR5Z0393
R7617 CHIP RES. 1/10W J 12k Ω RRXAJR5Z0123
R7701 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7702 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7715 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7716 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7723 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7724 CHIP RES. 1/10W J 100 Ω RRXAJR5Z0101
R7747 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7748 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R7755 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7756 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R7763 CHIP RES. 1/10W J 75 Ω RRXAJR5Z0750
R7764 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
R7797 METAL OXIDE FILM RES. 2W J 3.3 Ω RN023R3DP004
R7798 METAL OXIDE FILM RES. 2W J 3.3 Ω RN023R3DP004
R7800 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7801 CARBON RES. 1/4W J 680 Ω RCX4JATZ0681
R7802 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R7803 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R7804 CHIP RES. 1/10W J 150k Ω RRXAJR5Z0154
R7805 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
R7806 CHIP RES. 1/10W J 15k Ω RRXAJR5Z0153
R7807 CHIP RES. 1/10W F 2.2k Ω RRXAFR5H2201
R7809 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R7810 CARBON RES. 1/4W J 2.2k Ω RCX4JATZ0222
R7811 CHIP RES. 1/10W J 820 Ω RRXAJR5Z0821
R7812 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
MISCELLANEOUS
AC601# AC CORD A0A0280-007 WAC0172LTE04
B20 HEAT SINK PMQ A8AN0UH 1EM426178
B21 MODULE HEAT SINK PMC P7150UT 1EM423968
BC1 PCB JUMPER D0.6-P5.0 JW5.0T
BC2 PCB JUMPER D0.6-P5.0 JW5.0T
BC3 PCB JUMPER D0.6-P5.0 JW5.0T
BC4 CHIP INDUCTOR BK1608HS601-T LLC601NTU017
Ref. No. Description Part No.
BC601 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC636 PCB JUMPER D0.6-P5.0 JW5.0T
BC701 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC702 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
BC7206 BEADS INDUCTOR FBR07HA121SB-00 LLBF00STU030
F601# FUSE STC4A125V U/CT PAGE20CW3402
FH601 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
FH602 FUSE HOLDER MSF-015 LF (B110) XH01Z00LY002
J110 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
JK7501 JACK HPEP SML PCB S PJ-358H JXSJ020YUQ01
JK7701 JACK SW DIN PCB S 04/DIN-417HA-01 JYEJ040YUQ03
JK7702 JACK RCA PCB S YELLOW 01/RCA-101H(YL) JXRJ010YUQ05
JK7703 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK7704 JACK SW RCA PCB S RED RCA-102H(RD) JYRJ010YUQ03
JK7711 JACK RCA PCB S GREEN 01/RCA-101H(GN) JXRJ010YUQ03
JK7712 JACK RCA PCB S BLUE 01/RCA-101H(BL) JXRJ010YUQ04
JK7713 JACK RCA PCB S RED 01/RCA-101H(RD) JXRJ010YUQ01
JK7715 JACK RCA PCB S ORANGE 01/RCA-101H(OR) JXRJ010YUQ06
JK7716 JACK RCA PCB S WHITE 01/RCA-101H(WH) JXRJ010YUQ02
JK7717 JACK SW RCA PCB S RED RCA-102H(RD) JYRJ010YUQ03
L9 SCREW B-TIGHT D3X8 BIND HEAD+ GBJB3080
SA601# SURGE ABSORBER 470V+-10PER NVQZ10D471KB
T601# TRANS POWER 8718 LTT2PC0KT037
TM601 EYELET TYPE D-1 0VM406868
TM602 EYELET TYPE D-1 0VM406868
TU1 TUNER UNIT UA023AF UTUNATSSP006
Ref. No. Description Part No.
FUNCTION CBA(MPS-3)
Consists of the following:
----------
CAPACITOR
C110 CHIP CERAMIC CAP. F Z 0.01µF/50V CHD1JZ30F103
DIODE
D108 ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
RESISTORS
R120 CARBON RES. 1/4W G 6.8k Ω RCX4GATZ0682
R121 CARBON RES. 1/4W G 4.7k Ω RCX4GATZ0472
R122 CARBON RES. 1/4W G 2.7k Ω RCX4GATZ0272
R123 CARBON RES. 1/4W G 2.2k Ω RCX4GATZ0222
R124 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
R125 PCB JUMPER D0.6-P5.0 JW5.0T
R126 CARBON RES. 1/4W G 1.5k Ω RCX4GATZ0152
SWITCHES
SW108 TACT SWITCH SKQSAB SST0101AL038
SW109 TACT SWITCH SKQSAB SST0101AL038
SW110 TACT SWITCH SKQSAB SST0101AL038
SW111 TACT SWITCH SKQSAB SST0101AL038
SW112 TACT SWITCH SKQSAB SST0101AL038
SW113 TACT SWITCH SKQSAB SST0101AL038
SW114 TACT SWITCH SKQSAB SST0101AL038
MISCELLANEOUS
CL102 WIRE ASSEMBLY 001 6PIN / 280MM / AWG26 WX1A8AN0-001
Ref. No. Description Part No.
IR SENSOR CBA(MPS-4)
Consists of the following:
----------
CAPACITOR
C101 ELECTROLYTIC CAP. 47µF/16V M H7 CE1CMAVSL470
DIODES
Ref. No. Description Part No.
