Emerson LC195EM9 B Service Manual

20080422 13-5 A8AN5EL
MUT CBA
INVERTER CBA
D101 LED L-53HT NP4Z000L53HT
D102 LED GREEN 333GT/E(FNA) NPWZ33GTEFNA
RESISTORS
R101 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R102 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R103 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R104 CHIP RES. 1/10W J 220 Ω RRXAJR5Z0221
R105 CHIP RES. 1/10W J 1k Ω RRXAJR5Z0102
MISCELLANEOUS
BC101 PCB JUMPER D0.6-P5.0 JW5.0T
CL101 WIRE ASSEMBLY 002 5PIN / 150MM / AWG26 WX1A8AN0-002
RCV101 SENSOR REMOTE RECEIVER KSM-712TH2E USESJRSKK044
Ref. No. Description Part No.
MUT CBA
Consists of the following
1ESA17145
INVERTER CBA
JUNCTION CBA
----------
----------
Ref. No. Description Part No.
INVERTER CBA
Consists of the following:
----------
CAPACITORS
C401 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C402 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT018
C404 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C405 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT018
C406 CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C407 CHIP CERAMIC CAP.(1608) B K 4700pF/50V CHD1JK30B472
C408 CAP CHIP CERAMIC 5pF/3.15KV/DJ CA3F5R0MR060
C411 ELECTROLYTIC CAP. 10µF/50V M CE1JMASDL100
C412 ELECTROLYTIC CAP. 47µF/25V M CE1EMASDL470
C413 ELECTROLYTIC CAP. 1000µF/25V M CE1EMZNDL102
C414 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C415 CAP METALIZED FILM 0.11µF 250V H MPEF CT2E114DT065
C416 CAP CERAMIC HV 12P 3KV SL J CCD3FJPSL120
C417 CAP CERAMIC HV 12P 3KV SL J CCD3FJPSL120
C419 CHIP CERAMIC CAP.(1608) B K 0.01µF/50V CHD1JK30B103
C420 POLYESTER FILM CAP. (PB FREE) 0.1µF/100V
J
CA2A104DT018
C450 CHIP CERAMIC CAP. CH J 180pF/50V CHD1JJ3CH181
CONNECTORS
CN401 CONNECTOR PRINT OSU KW04-800-0200 J30402KET001
CN402 CONNECTOR PRINT OSU KW04-800-0200 J30402KET001
CN451 WIRE ASSEMBLY SPEAKER 2PIN 2PIN /95MM WX1A8AN0-003
DIODES
D402 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D403 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D405 ZENER DIODE MTZJT-7715B QDTB00MTZJ15
D408 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D409 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D410 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D411 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D412 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D413 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D414 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D415 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D416 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
Ref. No. Description Part No.
D418 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D419 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D422 SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D428 ZENER DIODE MTZJT-775.1B QDTB0MTZJ5R1
COILS
L401B POWER INDUCTER RCR1616-471K LLC471KSF009
L403 CHOKE COIL 22µH-K LLBD00PKV021
TRANSISTORS
Q401 TRANSISTOR 2SA950-O (TE2 F T) QQS002SA950F
Q402 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q403 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q404 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q405 TRANSISTOR 2SC2120-O(TE2 F T) QQS02SC2120F
Q406 NPN TRANSISTOR POWER 2SC4881F HFE
MAX320
QQWZ2SC4881F
Q408# FET MOS SMD HAT2215R01-EL-E QF2ZHAT2215R
Q410 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
Q411 TRANSISTOR KTA1267-GR-AT/P NQS1KTA1267P
Q412 TRANSISTOR KTC3199-GR-AT/P NQS4KTC3199P
RESISTORS
R401 CHIP RES. 1/10W J 1.5k Ω RRXAJR5Z0152
R402 CARBON RES. 1/4W J 27k Ω RCX4JATZ0273
R404 CHIP RES. 1/10W J 3.3k Ω RRXAJR5Z0332
R405 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R406 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R407 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R408 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R409 CARBON RES. 1/4W J 100 Ω RCX4JATZ0101
R412 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R413 CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R414 CHIP RES. 1/10W J 47 Ω RRXAJR5Z0470
R415 CHIP RES. 1/10W J 10k Ω RRXAJR5Z0103
R417 CARBON RES. 1/4W J 5.6k Ω RCX4JATZ0562
R418 CARBON RES. 1/4W J 330 Ω RCX4JATZ0331
R419 CHIP RES. 1/10W J 330 Ω RRXAJR5Z0331
R420 CHIP RES. 1/10W J 8.2k Ω RRXAJR5Z0822
R422 CHIP RES. 1/10W J 820k Ω RRXAJR5Z0824
R423 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R424 CHIP RES. 1/10W J 9.1k Ω RRXAJR5Z0912
R425 CHIP RES. 1/10W J 56 Ω RRXAJR5Z0560
R426 CHIP RES. 1/10W J 56 Ω RRXAJR5Z0560
R427 CHIP RES. 1/10W J 560k Ω RRXAJR5Z0564
R428 CHIP RES. 1/10W J 560k Ω RRXAJR5Z0564
R429 CHIP RES. 1/10W J 820k Ω RRXAJR5Z0824
R430 CARBON RES. 1/4W J 3.3 Ω RCX4JATZ03R3
R431 CHIP RES. 1/10W J 18k Ω RRXAJR5Z0183
R432 CHIP RES. 1/10W J 820 Ω RRXAJR5Z0821
R435 CHIP RES. 1/10W J 2.2k Ω RRXAJR5Z0222
R437 CARBON RES. 1/4W J 4.7k Ω RCX4JATZ0472
R438 CHIP RES. 1/10W J 560 Ω RRXAJR5Z0561
R439 METAL OXIDE FILM RES. 2W J 0.68 Ω RN02R68ZU001
R440 CHIP RES. 1/10W J 100k Ω RRXAJR5Z0104
R441 CHIP RES. 1/10W J 130k Ω RRXAJR5Z0134
R442 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R454 METAL OXIDE FILM RES. 2W J 0.33 Ω RN02R33ZU001
R455 CHIP RES. 1/10W J 22k Ω RRXAJR5Z0223
R456 CHIP RES.(1608) 1/10W 0 Ω RRXAZR5Z0000
MISCELLANEOUS
JS411 PCB JUMPER D0.6-P5.0 JW5.0T
T401# TRANS INVERTER ETJV26ZE11AC LTZ3PC0MS001
Ref. No. Description Part No.
