Figure i Model number nomenclature
UPS Single Module
Liebert NXf UPS module ratings:
10, 15, 20kVA (with internal battery)
Example: NXF0A0010U =
10kVA module for Europe and Middle East, 400V/230V
output
Options
Model
Identification Note
Battery cabinet NXE0NBCS
Battery Ground Fault detection kit NXA0UFXBGF
Battery temperature probe (for external battery) NXA0UFXBTS
Maintenance bypass cabinet (separate bypass
input)
NXF0NMBX Specify total system kVA
Fan Redundancy kit NXF0UFXRF
Specify UPS kVA rating
Seismic Anchor kit NXA0UFXSAN
Dual bus control cable 05-10-15 metres NXA0UFXDxx
Specify length in metres
Parallel control cable kit 05-10-15 metres NXA0UFXPxx
Relay Card (On Bat, Bat Low, On Byp, Sum, UPS
Fail)
MultiPort4 (4 sets On Bat, bat Low)
Web browser/TCPIP/SNMP Card
Jbus/Modbus Card
RELAYCARD-INT
MULTIPORT 4
OCWEB-LB
OC485CARD
These are Intellislot plug-in cards (3 slots
available).
RAM - Remote Alarm Monitor NXA0CFXRAM Requires RELAYCARD-INT
Extended LBS box NXA0UFXLBS
Air Filter NXE0UFXARF Each NXf contains two air filters
Dual Bus Extension Kit 50-150 Meters
NX150MLBSKIT (150m)
NX050MLBSKIT (50m)
Used for extension in length or dual bus
arrangement between Nx and non-Nx
sources
Individual Battery Monitoring
BDS 40 or
BDS 256
Specify number of blocks. Consult Emerson
Network Power representatives for
complete configuration
NXf U
NX Product Line
Revision
to Base
Unit
Feature Set for Region
A0 - EMEA
B0 - Aust/NZ
C0 - Japan
D0 - China
E0 - Latin Amer
F0 - Other
Input &
Output
Voltage
50/60Hz
Voltage Code
220/380 F
230/400 U
240/415 G
0A0010
Output kVA
010
015
020
