Technical Specifications
73
Table 32 Mechanical characteristics
Rated Power, kVA
Unit of
Measurement 10 15 20
Dimensions, WxDxH mm (in)
600x700x1400
(23-9/16x27-5/8x55)
Mass
Mass without batteries kg (lb) 180 (397) 200 (441) 200 (441)
Finish N/A
Pantone 877 (Silver grey)
equivalent Becker Silver epoxy polyester powder
041-37-2
Protection Degree, IEC (60529) N/A IP20 (finger-proof with front doors open or closed)
Table 33 Rectifier AC input (mains)
Rated power, kVA
Unit of
Measurement 10 15 20
Rated AC Input Voltage
1
VAC
380/400/415 (3-phase and sharing neutral with the bypass
input)
Input Voltage Tolerance
2
VAC 305V to 477V 304V to 208V (output derated below 70%)
Frequency
2
Hz 50/60Hz (tolerance 40Hz to 70Hz)
Power Factor
kW/kVA, full load
(half load)
0.99 (0.98)
Input Power
kVA rated
3
(maximum
4
)
10.0 (15.9) 13.9 (19.6) 18.4 (24.0)
Input Current
A rated
3
(maximum
4
)
15 (22) 20 (28) 27 (35)
Harmonic Current Distortion THDI % FL 3 3 3
Duration of Progressive
Power Walk-In
sec
10 seconds to reach full rated current (selectable 5 through 30
seconds in 5-second increments)
1. Rectifier operates at any of the rated supply voltages and frequencies without further adjustment.
2. At 305V input mains the UPS maintains the specified output voltage at rated load without discharging a previously charged
battery.
3. IEC 62040-3 / EN 50091-3: at rated load and input voltage 400V, battery charged
4. IEC 62040-3 / EN 50091-3: at rated load and input voltage 400V, battery charging at maximum rated power
