REV. 5 7/6/2007
Liebert Monitoring Group –Development
13
Input Power Supply Fail 10186 1 1
Input Over Voltage 10187 1 1
Input Under Voltage 10188 1 1
Bad Input Frequency 10190 1 1
Output Under Voltage 10218 1 1
Output Over Voltage 10219 1 1
Data Point
Input
Register
Holding
Register # of Reg. Scale Notes /Units
Number Of Input Lines 30004 40004 1 1 Bits 12 - 15
Number Of Bypass Lines 30004 40004 1 1 Bits 4 - 7
Number Of Output Lines 30004 40004 1 1 Bits 8 - 11
Number Of SubModules 30009 40009 1 1
Load Circuit Present 30013 40013 1
There are 16 possible Load
Circuits. So each bit
represents 1 load circuit.
Load Circuit 1 is bit 0, Load
Circuit 2 is bit 1 and so on. If
the bit is 1 then the Load
Circuit is supported.
Nominal Power Rating 30021 40021 2 1 VA
Nominal Input Voltage 30027 40027 1 1 V
Nominal Output Voltage 30028 40028 1 1 V
Nominal Input Current 30030 40030 1 1 A
Nominal Input Frequency 30031 40031 1 10 Hz
Nominal Output Frequency 30032 40032 1 10 Hz
Nominal Power Factor 30033 40033 1 100
Nominal Battery Voltage 30034 40034 1 1 V
Auto Restart Delay 30051 40051 1 1 seconds
Device Low Battery Time 30053 40053 1 1 min
Load (Apparent Power) 30102 2 1 VA
Load / Capacity 30106 1 1 %
Input Frequency 30107 1 10 Hz
Output Frequency 30108 1 10 Hz
Battery Charge Status 30112 1
1 - 100% Charged
2 - Less than 100% Charged
3 - Charging
4 - Discharging
5 - Float Charging
6 - Equalize Charging
Battery Voltage 30113 1 1 V
Battery Time Remaining 30115 1 1 min
Battery Charge Percentage 30116 1 1 %
Battery Test Result 30130 1 1
1 - Unknown
2 - Passed
3 - Failed
4 - In Progress
5 - System Failure
7 - Inhibited
Input Voltage L1 30153 1 1 V
