23
Input Current L2
30204 1 1
A
Input Voltage L3
30253 1 1
V
Input Current L3
30254 1 1
A
Liebert UPS Series 600
Supported Modbus Points
Data Point
Status Coil # of
Reg.
Scale
Notes / Units
Battery Charger On 10044 1 1
Battery Charge
Compensation
10046 1 1
Inverter Ready 10047 1 1
Auto Retransfer
Primed
10049 1 1
Load On Inverter 10073 1 1
Load On Bypass 10074 1 1
Buck On 10076 1 1
Battery data Buffer Full 10084 1 1
Shutdown Reason –
Hardware
10096 1 1
Load On Battery 10128 1 1
Manual Reset Transfer 10130 1 1
Load On Bypass
Permanent
10133 1 1
Load On Bypass-UPS
fault
10134 1 1
Battery Switch Open 10136 1 1
Input Switch Open 10137 1 1
Output Switch open 10138 1 1
Emergency Load
Transfer to Inverter
10145 1 1
Transfer inhibited –
Asynchronous
Sources
10146 1 1
Transfer inhibited –
over predefined limit
10147 1 1
SBS SCR Open 10149 1 1
SBS SCR Short 10150 1 1
Low Battery -
Shutdown Imminent
10152 1 1
Output Overload 10154 1 1
Over Temperature
Warning
10171 1 1
Battery Over
Temperature CB Trip
10172 1 1
Input Power Supply
Fail
10186 1 1
Input Under Voltage 10188 1 1
Input Brown Out 10189 1 1
