Liebert UPS Series 300

Supported Modbus Points

Data Point

Status Coil # of

Reg.

Scale

Notes / Units

Automatic Restart

Enabled

10001 1 1 1

Battery Charge

Compensation

10046 1 1

Inverter Ready 10047 1 1

Load Circuit 1 State 10057 1 1

Load Circuit 2 State 10058 1 1

Load Circuit 3 State 10059 1 1

Load Circuit 4 State 10060 1 1

Load Circuit 5 State 10061 1 1

Load Circuit 6 State 10062 1 1

Load Circuit 7 State 10063 1 1

Load Circuit 8 State 10064 1 1

Load Circuit 9 State 10065 1 1

Load Circuit 10 State 10066 1 1

Load Circuit 11 State 10067 1 1

Load Circuit 12 State 10068 1 1

Load Circuit 13 State 10069 1 1

Load Circuit 14 State 10070 1 1

Load Circuit 15 State 10071 1 1

Load Circuit 16 State 10072 1 1

Load On Inverter 10073 1 1

Bypass Active 10074 1 1

Buck On 10076 1 1

Replace Battery 10081 1 1

Battery Under Test 10082 1 1

Load On Battery 10128 1 1

Low Battery -

Shutdown Imminent

10152 1 1

Output Overload 10154 1 1

Over Temperature

Warning

10171 1 1

Battery Over

Temperature CB Trip

10172 1 1

Input Power Supply

Fail

10186 1 1

Input Over Voltage 10187 1 1

Input Under Voltage 10188 1 1

Bad Input Frequency 10190 1 1

Bypass Input

Voltage/Frequency

Fault

10202 1 1

Output Under Voltage 10218 1 1

Output Over Voltage 10219 1 1
