Emerson Liebert OpenComms-485 - Liebert DS

REV. 5 7/6/2007
Liebert Monitoring Group –Development
29
Liebert DS
Data points Mapped to Input Status and Coils
Reference Document: ST100I&C PA Parameters and Events, Version 18.0
Data Description Status Coil# #
bit
- Notes iCOM
Reference
Sleep on Monday 10001 1 1 U603
Sleep on Tuesday 10002 2 1 U603
Sleep on Wednesday 10003 3 1 U603
Sleep on Thursday 10004 4 1 U603
Sleep on Friday 10005 5 1 U603
Sleep on Saturday 10006 6 1 U603
Sleep on Sunday 10007 7 1 U603
Supply Limit Enable 10008 8 1 S105
Reheat Lockout 10009 9 1 S271
Humidifier Lockout 10010 10 1 S272
Temperature Indication [1] 10011 11 1 U404
Timer Mode Type 10012 12 1 U610
Minimum Chilled Water Temp
Enable
10013 13 1 S128
Std. Sensor Alarms Enable 10019 19 1 U202
Sensor A Alarms Enable 10020 20 1 U207
Compressor Lockout 10021 21 1 S274
VSD Fan speed 10022 22 1 S131
Unit Control - 25 1
EnvState.
SysCtrl
Reset Alarm - 26 1 ..
EnvState.
AlarmCtrl.1
Acknowledge Alarm - 27 1 ..
EnvState.
AlarmCtrl.2
Reset Total Run Hours Fan
Motor
- 28 1 ..
U502
Reset Comp1Run Hour - 29 1 ..
U503
Reset Comp2Run Hour - 30 1 ..
U504
Reset Humidifier Run Hour - 31 1 ..
U510
Reset Dehumidifier Run Hour - 32 1 ..
U511
Reset CW/FC Run Hour - 33 1 ..
U505
Reset E-Heater1RunHour - 34 1 ..
U507
Reset E-heater2RunHour - 35 1 ..
U508
Reset E-heater3 Run Hour - 36 1 ..
U509
Reset HG/HW Run Hour - 37 1 ..
U506
Fan On 10025 - 1
FanSym
Cool On 10026 - 1
CoolSym
Free Cool On 10027 - 1
FCSym
Hot Water On 10028 - 1
HWSym
Electrical Heater On 10029 - 1
HeatSym
