Emerson MP75A4 - Figure 3-11 Size 2 D Front View and Mounting Dimensions

Safety
Information
Product
information
Mechanical
Installation
Electrical
installation
Getting
started
Basic
parameters
Running the
motor
Optimization
SMARTCARD
operation
Onboard
PLC
Advanced
parameters
Technical
data
Diagnostics
UL
information
22 Mentor MP User Guide
www.controltechniques.com Issue: 3
Figure 3-11 Size 2D front view and mounting dimensions
124m
m
(4.88
i
n
)
6mm
(0.24in)
1065mm (41.93in)
356mm (14.02in)
248mm (9.76in)
405mm (15.94in)
4mm
(0.16in)
321mm (12.64in)
330mm (13.0in)
555mm (21.85in)
330mm (13.0in)
330mm (13.0in)
452mm (17.8in)
202mm (7.95in)
390mm (15.35in)
