Mentor MP User Guide 119
Issue: 3 www.controltechniques.com
Parameter
Range(
Ú) Default(Ö)
Type
8.01 T24 digital I/O 1 state {in05, 0.85}
OFF (0) or On (1)
RO Bit NC PT
8.02 T25 digital I/O 2 state {in06, 0.86} RO Bit NC PT
8.03 T26 digital I/O 3 state {in07, 0.87} RO Bit NC PT
8.04 T27 digital input 4 state {in08, 0.88} RO Bit NC PT
8.05 T28 digital input 5 state {in09, 0.89} RO Bit NC PT
8.06 T29 digital input 6 state {in10, 0.90} RO Bit NC PT
8.07 T51, 52, 53 relay state RO Bit NC PT
8.09 T31 drive enable state RO Bit NC PT
8.10 Enable mode select 0 to 2 0 RW Uni US
8.11 T24 digital I/O 1 invert
OFF (0) or On (1) OFF (0)
RW Bit US
8.12 T25 digital I/O 2 invert RW Bit US
8.13 T26 digital I/O 3 invert RW Bit US
8.14 T27 digital input 4 invert RW Bit US
8.15 T28 digital input 5 invert RW Bit US
8.16 T29 digital input 6 invert RW Bit US
8.17 T51, 52, 53 relay invert RW Bit US
8.20 Digital I/O read word 0 to 4095
RO Uni NC PT
8.21 T24 digital I/O 1 source/ destination
Pr 0.00 to 22.99
Pr 10.06 RW Uni DE PT US
8.22 T25 digital I/O 2 source/ destination Pr 10.33 RW Uni DE PT US
8.23 T26 digital I/O 3 source/ destination Pr 6.30 RW Uni DE PT US
8.24 T27 digital input 4 destination Pr 6.32 RW Uni DE PT US
8.25 T28 digital input 5 destination Pr 1.41 RW Uni DE PT US
8.26 T29 digital input 6 destination Pr 6.31 RW Uni DE PT US
8.27 T51, 52, 53 relay source Pr 10.01 RW Uni PT US
8.29 I/O polarity select 2 1 RW Uni PT US
8.30 Open collector output
OFF (0) or On (1)
OFF (0) RW Bit US
8.31 T24 digital I/O 1 output select On (1) RW Bit US
8.32 T25 digital I/O 2 output select
OFF (0)
RW Bit US
8.33 T26 digital I/O 3 output select RW Bit US
8.40 T61, 62, 63 relay state RO Bit NC PT
8.41 Start button state
RO Bit NC PT
8.42 Forward/reverse button state OFF (0) RO Bit NC PT
8.48 24V input state
RO Bit NC PT
8.50 T61, 62, 63 relay invert
OFF (0)
RW Bit US
8.52 Toggle enable RW Bit US
8.60 T61, 62, 63 relay destination
Pr 0.00 to 22.99
Pr 6.55 RW Uni DE PT US
8.61 Start button destination
Pr 0.00
RW Uni DE PT US
8.62 Forward/reverse button destination RW Uni DE PT US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
