120 Mentor MP User Guide
www.controltechniques.com Issue: 3
11.9 Menu 9: Programmable logic, motorized pot and binary sum
Figure 11-12 Menu 9 logic diagram: Programmable logic
??.??
Any
unprotected
bit
parameter
??.??
9.10
Function-1
destination
parameter
??.??
Any bit
parameter
??.??
x(-1)
9.04
Function-1 input-1
source parameter
9.05
Function-1
input-1 invert
??.??
Any bit
parameter
??.??
x(-1)
9.06
Function-1 input-2
source parameter
9.07
Function-1
input-2 invert
9.08
Function-1
output invert
9.09
Function-1
delay
x(-1)
Function-1
output
indicator
9.01
??.??
Any
unprotected
bit
parameter
??.??
9.20
Function-2
destination
parameter
??.??
Any bit
parameter
??.??
x(-1)
9.14
Function-2 input-1
source parameter
9.15
Function-2
input-1 invert
??.??
Any bit
parameter
??.??
x(-1)
9.16
Function-2
input-2
source
parameter
9.17
Function-2
input-2 invert
9.18
Function-2
output invert
9.19
Function-2
delay
x(-1)
Function-2
output
indicator
9.02
0.XX
0.XX
Key
Read-write
(RW)
parameter
Read-only (RO)
parameter
Input
terminals
Output
terminals
The parameters are all shown at their default settings
9.37
Function 1
mode
9.38
Function 2
mode
