122 Mentor MP User Guide
www.controltechniques.com Issue: 3
Parameter
Range(
Ú)Default(Ö)
Type
9.01 Logic function 1 output
OFF (0) or On (1)
RO Bit NC PT
9.02 Logic function 2 output RO Bit NC PT
9.03 Motorized pot output ±100.00% RO Bit NC PT PS
9.04 Logic function 1 source 1 Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.05 Logic function 1 source 1 invert OFF (0) or On (1) OFF (0) RW Bit US
9.06 Logic function 1 source 2 Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.07 Logic function 1 source 2 invert
OFF (0) or On (1) OFF (0)
RW Bit US
9.08 Logic function 1 output invert RW Bit US
9.09 Logic function 1 delay ±25.0s 0.0 RW Bi US
9.10 Logic function 1 destination
Pr 0.00 to 22.99 Pr 0.00
RW Uni PT US
9.14 Logic function 2 source 1 RW Uni PT US
9.15 Logic function 2 source 1 invert OFF (0) or On (1) OFF (0) RW Bit US
9.16 Logic function 2 source 2 Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.17 Logic function 2 source 2 invert
OFF (0) or On (1) OFF (0)
RW Bit US
9.18 Logic function 2 output invert RW Bit US
9.19 Logic function 2 delay ±25.0s 0.0 RW Bi US
9.20 Logic function 2 destination Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.21 Motorized pot mode 0 to 3 2 RW Uni US
9.22 Motorized pot bipolar select OFF (0) or On (1) OFF (0) RW Bit US
9.23 Motorized pot rate 0 to 250s 20 RW Uni US
9.24 Motorized pot scale factor 0 to 4.000 1.000 RW Uni US
9.25 Motorized pot destination Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.26 Motorized pot up
OFF (0) or On (1) OFF (0)
RW Bit NC
9.27 Motorized pot down RW Bit NC
9.28 Motorized pot reset RW Bit NC
9.29 Binary sum ones input RW Bit NC
9.30 Binary sum twos input RW Bit NC
9.31 Binary sum fours input RW Bit NC
9.32 Binary sum output 0 to 255
RO Uni NC PT
9.33 Binary sum destination Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.34 Binary sum offset 0 to 248 0 RW Uni US
9.35 Up down disable source Pr 0.00 to 22.99 Pr 0.00 RW Uni PT US
9.36 Up down disable invert OFF (0) or On (1) OFF (0) RW Bit US
9.37 Logic block 1 mode
0 to 4 0
RW Uni US
9.38 Logic block 2 mode RW Uni US
RW Read / Write RO Read only Uni Unipolar Bi Bi-polar Bit Bit parameter Txt Text string
FI Filtered DE Destination NC Not copied RA Rating dependent PT Protected US User save PS Power down save
