18
This diagram shows that there are 6 CDs in the changer. The half circles above the
disc numbers indicate that Discs 1, 2, and 6 are at the back half of the drawer. The
half circles below the disc numbers indicate that Discs 3, 4, and 5 are at the front
half of the drawer. The flashing number 1 indicates that Disc 1 is in the play position.
The display also indicates that Disc 1 has 22 tracks and a total playing time of
61 minutes and 14 seconds. If the PLAY button is pressed in this illustration the
number 1 will stop flashing and the half circle above the number will begin to flash
indicating that Disc 1 is playing. Refer to the following illustration:
As each disc plays and the drawer rotates the disc location icons will show which
discs are at the back of the drawer and which discs are at the front of the drawer.
NORMAL PLAYBACK
1.) Press the CD function button to turn the power ‘On’ and select the CD function.
2.) Press the lower half ‘FRONT’ of the OPEN/CLOSE button on the front panel,
or the FRONT open button on the remote control, to open the CD drawer
immediately. As the drawer opens the front edge of the drawer drops down
slightly to allow easier access to the lower tray. See following illustration.
CD
TRACK
LOWER TRAY
LOWER TRAY
UPPER TRAY
MS9600_ib_0313.p65 25/3/2002, 15:2318
