Quick Start Guide Section 3
GFK-2941K Sep 2019
Module Start-up 14
3. Module Start-up
3.1. You Will Need:
• An RX3i Universal Backplane: IC695CHS007, IC695CHS012 or IC695CHS016.
• This PACSystems RX3i CPU. This CPU occupies two backplane slots.
• An RX3i rack-mounted Power Supply Module and compatible power source
(AC
or DC).
• A computer running PAC Machine Edition (PME) configuration and
programming software. PME Version 8.60 SIM 8 or later supports all features
in this document.
• Ethernet cable for connecting the PME programmer computer to the RX3i CPU.
• Phillip’s head screwdriver.
• Very small slotted screwdriver (1.4mm jeweler’s size).
3.2. Basic Installation Steps:
For startup and configuration of the CPE330, complete the following steps. For full
details on CPE330 operation, refer to the PACSystems RX7i, RX3i & RSTi-EP CPU
Reference Manual, GFK-2222V or later.
1. Turn power off at the RX3i rack and install the CPE330 in a double-slot which is
CPU-compatible (refer to PACSystems RX3i System Manual, GFK-2314 Chapter
3). Typically, the CPU is in the left-most slot pair, or in the pair of slots to the right
of the power supply module.
Note: on lightly-loaded racks, use IC695PSA040H or later, or IC695PSA140D or later, otherwise
power-up may be unsuccessful. Alternately, fill out the empty slots in the rack to draw more
current.
To Next Page
