Quick Start Guide Section 1
GFK-2941K Sep 2019
User Features 4
signals are decoded by the PNS101 using either an IC695HSC304 or IC695HSC308
High Speed Counter Module. SoE recording is available in both simplex and
redundant PROFINET systems.
• User may program in Ladder Diagram, Structured Text, Function Block Diagram, or
C.
• Contains 64Mbytes of configurable data and program memory.
• Supports auto-located Symbolic Variables that can use any amount of user
memory.
• Reference tables include 32k bits for discrete %I and %Q and up to 32k words each
for analog %AI and %AQ. Bulk memory (%W) also supported for data exchanges.
• Supports up to 768 program blocks. Maximum size for a block is 128KB.
• For supported I/O, Communications, Motion, and Intelligent modules, refer to the
PACSystems RX3i System Manual, GFK-2314.
• Ability to display serial number and date code in PME Device Information Details.
• Coordinated Universal Time (UTC) and Day Light Savings Time (DST) support.
• Operating temperature range 0C to 60C (32 F to 140 F).
1.1. Switches
The Run/Stop switch and RDSD UPLD and RDSD DNLD pushbuttons are located
behind the protective front door. Switch operation is given in the following table.
