Emerson QuickPanel+ IC755C S12CD Series Quick Start Guide

Quick Start Guide Section 4
GFK-2893P Sep 2019
Mounting & Installation 22
Figure 4.5: IC755CxS12CDx Mounting Holes
Figure 4.6: IC755CxS15CDx Mounting Holes
4.4 Mounting and Installation
Procedure
CAUTION
• When installing the Quick Panel
+
into the panel, pay
careful attention while handling the unit so it does
not drop and damage the unit.
➢ To install the Quick Panel
+
1. Cut an opening in the panel according to the
specifications in the following figures.

Emerson QuickPanel+ IC755C S12CD Series Specifications

General

Brand	Emerson
Model	QuickPanel+ IC755C S12CD Series
Category	Monitor
Language	English
