Section 1: Specifications
1.1 Specifications
Specifications 1
Instruction Manual Specifications
LIQ-MAN-PERpH-X April 2017
Table 1-2: Rosemount 3300HT/3300HTVP sensor specifications
Measured Range
pH range 0 to 14 pH
ORP range -1500 mV to 1500 mV
Operating Temperature
Without Preamplifier 41 to 311 °F (5 to 155 °C)
With Preamplifier up to 212 °F (100 °C)
Storage Temperature
14 to 138 °F (-10 to 70 °C)
Maximum Process Pressure
400 psig (2859 kPa [abs])
CRN Rating: 200 psig at room temperature
Wetted Materials
Titanium, Ryton, Teflon, Glass, and User Specified O-ring Material (EPDM, Viton or Kalrez)
Reference Electrode
Double junction with replaceable process side electrolyte and Teflon junction
Temperature Sensor
Pt-100 RTD
Process Connections
Must use 1 in. compression process connector (P/N 23166-00 or 23166-01)
Weight/Shipping Weight
1 lb/2 lb (0.5 kg/0.9 kg)
Cable Length
15 ft. integral cable (Rosemount 3300HT) or VP8 Cable for Rosemount 3300HTVP (sold separately)
pH Range HT Series
0-2 pH 94%
2-12 pH 99%
12-13 pH 97%
13-14 pH 92%
Table 1-1: Percent linearity over pH
