Quick Installation Guide
00825-0100-4662, Rev CC
December 2012
Rosemount 8732
31
ED ATEX Flameproof
Certificate No: KEMA 07ATEX0073 X
II 2G Ex de IIB T6 or
II 2G Ex de [ia] IIB T6
without LOI (-50 °C  Ta  +60 °C)
with LOI (-20 °C  Ta  +60 °C)
V
max
= 250 V AC or 42 V DC
0575
ND ATEX Dust
Certificate No: KEMA 07ATEX0073 X
II 1D Ex tD A20 IP66 T100 °C or
with I.S. outputs
II G [Ex ia] IIC
without LOI (-50 °C  Ta  +60 °C)
with LOI (-20 °C  Ta  +60 °C)
V
max
= 250 V AC or 42 V DC
IP 66
0575
Special Conditions for Safe Use (KEMA 07ATEX0073X):
Contact Rosemount Inc. for information on the dimensions of the flameproof joints. The
property class of the security screws which attach the flowtube or junction box to the
transmitter is SST A2-70.
Installation Instructions:
The cable and conduit entry devices and blanking elements shall be of a certified
flameproof type, suitable for the conditions of use and correctly installed. With the use of
conduit, a certified stopping box shall be provided immediately to the entrance of the
enclosure.
N1 ATEX Type n
Certificate No: Baseefa 07ATEX0203X
II 3G Ex nA nL IIC T4
without LOI (-50 °C  Ta  +60 °C)
with LOI (-20 °C  Ta  +60 °C)
V
max
= 42 V DC
IP 66
0575
Special Conditions for Safe Use (x):
The apparatus is not capable of withstanding the 500V electrical strength test required
by Clause 6.8.1 of EN 60079-15: 2005. This must be taken into account when installing
the apparatus.
