Emerson Process Management GmbH & Co. OHG 6-47
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
6
Software Menus
6.2.3.3.1.2.1 Autoranging Switchover Levels
6.2.3 Setup Menu
Specify individual switchover levels, instead
of using one single hysteresis value for all
ranges.
Max. level gives the switchover limit for rising
concentrations: If this level is exceeded, the
analyzer activates the next higher range.
Min. level gives the switchover limit for de-
creasing concentrations: If this level is under-
run, the analyzer activates the next lower
range.
Setup..
Measurement..
Ranges..
Autoranging..
Switchover Levels..
Ch1
Switchover Levels
MaxLevel1: 500.000 ppm
MinLevel2: 400.000 ppm
MaxLevel2: 750.000 ppm
MinLevel3: 600.000 ppm
MaxLevel3: 2000.000 ppm
MinLevel4: 1800.000 ppm
Note!
As given in the gures to the left, specifying
the 'Min.level' of a level to be lower than the
'Max.level' of the level right below, denes a
switching hysteresis.
To Next Page
