Emerson Process Management GmbH & Co. OHGA-40
X-STREAM XE
Instruction Manual
HASXEE-IM-HS
10/2012
PLCQuickReferenceCard
Rev.2010‐10
ChannelActionsPoolIndex
Usageexample:CALL A103; Start span cal for channel 1, if register changed to TRUE
#Replace ‘x’ in table by channel # (1 … 5)
ANR Description ANR Description
x01 None x12 MaintRequ
x02 ZeroCal X x13 FctCheck
x03 SpanCal x14 Sample Gas
x04 ZeroSpanCal x15 ZeroGas
x05 Cancel x16 SpanGas1
x06 Range1 x17 SpanGas2
x07 Range2 x18 SpanGas3
x08 Range3 x19 SpanGas4
x09 Range4 x20 AllClosed
x10 Failure x21 Blowback
x11 OffSpec
ChannelDigitalOutputPoolIndex
Usageexample:LOAD S332; Load press low alarm state of channel 3 into register
#Replace ‘x’ in table by channel # (1 … 5)
SNr Description SNR Description
x01 Off x21 Conc.Hi
x02 On x22 Conc.HiHi
x03 Heartbeat x23 AverageLoLo
x04 Failure x24 AverageLo
x05 OffSpec x25 AverageHi
x06 MaintRequ x26 AverageHiHi
x07 FctCheck x27 Temperature LoLo
x08 Calibrating x28 TemperatureLo
x09 Zeroing x29 TemperatureHi
x10 Spanning x30 TemperatureHiHi
x11 ZeroFailed x31 PressureLoLo
x12 SpanFailed x32 PressureLo
x13 RangeUnderflow x33 PressureHi
x14 RangeOverflow x34 PressureHiHi
x15 Range1 x35 FlowLoLo
x16 Range2 x36 FlowLo
x17 Range3 x37 FlowHi
x18 Range4 x38 FlowHiHi
x19 Conc.LoLo x39 Off
x20 Conc.Lo x40 Off
A.7 PLC Quick Reference
