Emerson Tescom ER5000 Series

ER5000 —
169
The ERTune™ Program: Basic Features
Digital Output (ER Outputs are Ports 3 & 4)
Sends a signal to trigger a process in another part of the system.
Refer to the Digital Outputs wiring conguration for an example
of an ER5000 with digital outputs.
Enter the ER5000 port number for the digital output in the Port
Number eld and the ER5000 port state (0 => open circuit, 1=>
closed circuit) in the Port State entry eld.
Digital Input (ER Input is Port 3)
Pauses the Prole until the specied input is set to the specied
state. Refer to the Prole with External Control/Digital Inputs
wiring conguration for an example of an ER5000 with
digital inputs.
Enter the ER5000 port number for the digital input in the Port
Number eld and the ER5000 port state (0 => open circuit, 1=>
closed circuit) in the Port State entry eld.
