Unidrive M100-101 Quick Start Guide 15
Issue Number: 6
Figure 4-7 Pr 00.005 = AI.Pr (50 Hz)
Figure 4-8 Pr 00.005 = AI.Pr (60 Hz)
Figure 4-9 Pr 00.005 = Preset (50 Hz)
* Refer to Drive User Guide.
1
2
4
9
0 V
Current speed
reference input (AI 1)
Reference select
Reference select
10
11
12
13
Drive enable
Run forward
+ 10 V output
+ 24 V output
Current speed
reference input
Terminal 10 Terminal 13 Reference selected
0 0 Analog reference 1*
0 1 Preset speed 2*
1 0 Preset speed 3*
1 1 Preset speed 4*
1
2
4
9
0 V
Current speed
reference input (AI 1)
Reference select
Reference select
10
11
12
13
Not stop
Run
+ 10 V output
+ 24 V output
Current speed
reference input
Terminal 10 Terminal 13 Reference selected
0 0 Analog reference 1*
0 1 Preset speed 2*
1 0 Preset speed 3*
1 1 Preset speed 4*
1
2
4
9
0V
Voltage speed
reference input (AI 1)
Reference select
Reference select
10
11
12
13
Drive enable
Run forward
+ 10 V output
+ 24 V output
Terminal 10 Terminal 13 Reference selected
0 0 Preset speed 1*
0 1 Preset speed 2*
1 0 Preset speed 3*
1 1 Preset speed 4*
