Unidrive M100-101 Quick Start Guide 21
Issue Number: 6
6 Basic parameters (Menu 0)
Menu 0 is used to bring together various commonly used parameters for basic easy set up of the
drive. All the parameters in Menu 0 appear in other menus in the drive. Menus 22 can be used to
configure the parameters in Menu 0.
6.1 Menu 0: Basic parameters
Parameter
Range (Ú) Default (Ö)
Type
OL OL
00.001
Minimum Reference
Clamp
±VM_NEGATIVE_REF_CLAMP 1 Hz 0.00 Hz RW Num US
00.002
Maximum
Reference Clamp
±VM_POSITIVE_REF_CLAMP Hz
50 Hz default: 50.00 Hz
60 Hz default: 60.00 Hz
RW Num US
00.003 Acceleration Rate 1 ±VM_ACCEL_RATE s 5.0 s RW Num US
00.004 Deceleration Rate 1 ±VM_ACCEL_RATE s 10.0 s RW Num US
00.005 Drive Configuration
AV (0), AI (1), AV.Pr (2), AI.Pr (3),
Preset (4), Pad (5), Pad.Ref (6),
torque (8)
AV (0)*
RW Txt PT US
00.006 Motor Rated Current 0.00 to VM_RATED_CURRENT A
Maximum Heavy Duty
Rating (11.032) A
RW Num RA US
00.007 Motor Rated Speed 0.0 to 80000.0 rpm
50 Hz default:
1500.0 rpm
60 Hz default:
1800.0 rpm
RW Num US
00.008 Motor Rated Voltage 0 to VM_AC_VOLTAGE_SET V
110 V drive: 230 V
200 V drive: 230 V
400 V drive 50 Hz: 400 V
400 V drive 60 Hz: 460 V
RW Num RA US
00.009
Motor Rated Power
Factor
0.00 to 1.00 0.85 RW Num RA US
00.010 User Security Status
LEVEL.0 (0), ALL (1), r.only.0 (2),
r.only.A (3), Status (4), no.acc(5)
LEVEL.0 (0) RW Num ND NC PT
00.015 Jog Reference 0.00 to 300.00 Hz 1.50 Hz RW Num US
00.016
Analog Input 1
Mode
4-20.S (-6), 20-4.S (-5), 4-20.L (-4),
20-4.L (-3), 4-20.H (-2), 20-4.H (-1),
0-20 (0), 20-0 (1), 4-20.tr (2), 20-4.tr (3),
4-20 (4), 20-4 (5), Volt (6)
Volt (6) RW Txt US
00.017
Bipolar Reference
Enable
Off (0) or On (1) Off (0) RW Bit US
00.018 Preset Reference 1 ±VM_SPEED_FREQ_REF Hz 0.00 Hz RW Num US
00.025 User Security Code 0 to 9999 0 RW Num ND NC PT US
00.027
Power-up Keypad
Control Mode
Reference
Reset (0), Last (1), Preset (2) Reset (0) RW Txt US
00.028 Ramp Mode Select Fast (0), Std (1), Std.bst (2), Fst.bst (3) Std (1) RW Txt US
00.030 Parameter Cloning
None (0), rEAd (1), Prog (2), Auto (3),
boot (4)
None (0) RW Txt NC US
00.031 Stop Mode
Coast (0), rp (1), rp.dc I (2), dc I (3),
td.dc I (4),dis (5), No.rp (6)
rp (1) RW Txt US
00.032
Dynamic V to F
Select
0 to 1 0 RW Num US
00.033
Catch A Spinning
Motor
dis (0), Enable (1), Fr.Only (2),
Rv.Only (3)
dis (0) RW Txt US
00.035
Digital Output 1
Control
0 to 21 0 RW US
00.037
Maximum Switching
Frequency
0.667 (0), 1 (1), 2 (2), 3 (3), 4 (4),
6 (5), 8 (6), 12 (7), 16 (8) kHz
3 (3) kHz RW Txt US
