00.038 Autotune 0 to 2 0 RW Num NC US
00.039
Motor Rated
Frequency
0.00 to
VM_SPEED_FREQ_REF_UNIPOLAR
Hz
50 Hz: 50.00 Hz
60 Hz: 60.00 Hz
RW Num US
00.040
Number of Motor
Poles
Auto (0) to 32 (16) Auto 0 RW Num US
00.041 Control Mode
Ur.S (0), Ur (1), Fd (2), Ur.Auto (3),
Ur.I (4), SrE (5), Fd.tap (6)
Ur.I (4) RW Txt US
00.042
Low Frequency
Voltage Boost
0.0 to 25.0 % 3.0 % RW Num US
00.069 Spin Start Boost 0.0 to 10.0 1.0 RW US
00.076
Action on Trip
Detection
0 to 31 0 RW US
00.077
Maximum Heavy
Duty Current Rating
0.00 to 9999.99 A RO Num ND NC PT
00.078 Software Version 0 to 999999 RO ND NC PT
00.079 User Drive Mode OPEn.LP (1) OPEn.LP (1) RW Txt ND NC PT US
RW
Read /
Write
RO
Read
only
Num
Number
parameter
Bit
Bit
parameter
Txt Text string Bin
Binary
parameter
FI Filtered
ND
No
default
value
NC
Not
copied
PT
Protected
parameter
RA
Rating
dependent
US User save PS
Power-down
save
DE Destination
Parameter
Range (Ú) Default (Ö)
Type
OL OL
Unidrive M100 101 Quick Start Guide English Iss6.book Page 22 Wednesday, September 9, 2015 4:07 PM
