Unidrive M100-101 Quick Start Guide 27
Issue Number: 6
Use Pr 00.005 to select the required frequency/speed reference as follows:
* Refer to the Drive User Guide.
The rated current parameter must be set to the maximum continuous current of the motor (taken
from the name plate). The motor rated current is used in the following:
• Current limits
• Motor thermal overload protection
• Vector mode voltage control
• Slip compensation (see Enable Slip Compensation). Refer to the Drive User Guide.
• Dynamic V/F control
Set to the rated speed of the motor (taken from the motor name plate). The motor rated speed is
used to calculate the correct slip speed for the motor.
00.005 {11.034} Drive Configuration
RW Txt PT US
OL
Ú
AV (0), AI (1), AV.Pr (2), AI.Pr (3),
Preset (4), Pad (5), Pad.Ref (6),
torque (8)
Ö
AV (0)
Value Text Description
0AV
Analog input 1 (voltage)
1AI
Analog input 1 (current)
2AV.Pr
Analog input 1 (voltage) or 3 presets selected by terminal
3AI.Pr
Analog input 1 (current) or 3 presets selected by terminal
4Preset
Four presets selected by terminal
5Pad
Keypad reference
6 Pad.Ref
Keypad reference with terminal control
8 torque
Torque mode, Analog input 1 (voltage torque reference) selected by terminal
A change to Pr 00.005 is set by pressing the MODE key on exit from parameter edit mode.
The drive must be disabled, stopped or tripped for a change to take place. If Pr 00.005 is
changed while the drive is running, when the MODE key is pressed on exit from parameter
edit mode, Pr 00.005 will change back to its previous value.
When the setting of Pr 00.005 is changed, the appropriate drive configuration parameters
are set back to their default values.
00.006 {05.007} Motor Rated Current
RW Num RA US
OL
Ú
0.00 to VM_RATED_CURRENT A
Ö
Maximum Heavy Duty Rating A*
00.007 {05.008} Motor Rated Speed
RW Num US
OL
Ú
0.0 to 80000.0 rpm
Ö
50Hz default: 1500.0 rpm
60Hz default: 1800.0 rpm
NOTE
NOTE
