Emerson Unidrive M201 - Page 112

112 SI-Ethernet User Guide
Issue: 1
S.22.014 Output mapping parameter 14
Minimum
0
(Display: 0.00.000)
Maximum
499999
(Display: 4.99.999)
Default
0
(Display: 0.00.000)
Units
Type 32 Bit User Save Update Rate
Module reset, EtherNet/IP
interface reset or EtherNet/
IP interface enable
Display Format Slot Menu Param Decimal Places 0
Coding RW, DE, PT, BU
S.22.015 Output mapping parameter 15
Minimum
0
(Display: 0.00.000)
Maximum
499999
(Display: 4.99.999)
Default
0
(Display: 0.00.000)
Units
Type 32 Bit User Save Update Rate
Module reset, EtherNet/IP
interface reset or EtherNet/
IP interface enable
Display Format Slot Menu Param Decimal Places 0
Coding RW, DE, PT, BU
S.22.016 Output mapping parameter 16
Minimum
0
(Display: 0.00.000)
Maximum
499999
(Display: 4.99.999)
Default
0
(Display: 0.00.000)
Units
Type 32 Bit User Save Update Rate
Module reset, EtherNet/IP
interface reset or EtherNet/
IP interface enable
Display Format Slot Menu Param Decimal Places 0
Coding RW, DE, PT, BU
S.22.017 Output mapping parameter 17
Minimum
0
(Display: 0.00.000)
Maximum
499999
(Display: 4.99.999)
Default
0
(Display: 0.00.000)
Units
Type 32 Bit User Save Update Rate
Module reset, EtherNet/IP
interface reset or EtherNet/
IP interface enable
Display Format Slot Menu Param Decimal Places 0
Coding RW, DE, PT, BU
